Engraving Acrylic Mirror Board

FOB Price

USD $13.2 - $115 / Kilogram

1000 Kilograms(Min.Order)

Supply Ability 100 Ton / Tons per Month
Port SHANGHAI PORT CHINA
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Shanghai, China	Brand Name:	oursign	Model Number:	OS-AM
Material:	Other, Acrylic, pmma/ps	Thickness:	1~6mm	Size:	12201830mm 12202440mm

Product Description

Colors Pmma mirror sheet

Introduction:

Cast Acrylic sheet has excellent light transmittance, higher mechanical strength. It is also light-weight, good weather resistance, corrosion resistance, good insulation properties, easily be processed. The board can be used for a certain strength requirements of the transparent structure, the cups, lamps, instrument parts, optical lenses, decorative gifts and so on. At present, the material widely used in advertising light box, signs, handicrafts, etc.

Features:

1. excellent light transmittance.

2. high mechanical strength.

3. weather proof

4. non-toxic and chemical resistant.

5. easily be processed

Application:

1. Advertisement: blow molding board, CNC engraving materials, Laser engraving materials, sign board, logo and mark, etc.

2. Furnitureoffice furniture, cabinet, bath cabinet, etc.

3. Finishing Materialdecorative sheets, storage racks, room segments, etc.

4. Handicrafts, toys, etc.

Specification:

Name	Colors	Standard Size(mm)	Thickness±0.1(mm)
Acrylic(PMMA)	Silver	12201830 12202440	2-4

	Gold ,Red,Yellow,Blue,Green	12201830 12202440

Mechanical Property:

Physical Property		Unit	Value
Optical	Light Transmittance	%	91
Optical	Refractive Index	%	1.49
Thermal	The application of temperature		-40~70
	Hot Forming Temp		140~180
	Heat Distortion Temp		87
	Coefficient Of Liner Thermal Expansion	1/	1.7*10^-4
	Specific Heat	kj/(kg.)	1.25~1.7
Mechanical	Specific Gravity(30/4)	g/cm³	1.19~1.2
	Tensile Strength	mpa	62~75
	compressive Strength	mpa	130
	Impact Strength	kj/m²	12.1~12.8
	Rockwell Hardness		95
Electrical	Surface Resistivity	Ω	10¹⁶
	20 Volume Resistivity	Ω.m	10¹⁵
	Flammability	mm/min	33
Miscellaneous	Water Absorption(24Hrs)	%	0.3
Miscellaneous	Odor		None
