Specifications
oil rig drilling elevator link1.Manufacturer
2.best quality
3.good afer-sale services
4.fast delivery
30T- 350T oil rig drilling elevator link
30T- 350T oil rig drilling elevator link
Product Description
1.high quality, competitive price
2.advance forging and heat-treatment technology
3.strength and nondestructive test
plete specification, extensive use, solid structure
ed factor :3
6.its strength is verified throughout tensile test:1.5 WLL
7.there are signs such as WORKING LOAD LIMIT in the link
8.painted surface
Application: elevator link is an indispensible tool to lift and drop the elevators for oilfield and gas well operation.
Technical specification and parameters
| model | rated load | size between elevators and elevator links | L(mm) | ||||
| r1 | R1 | L1 | L2 | L3 | |||
| DH40 | 355 | <=20 | >=51 | >=20 | >=100 | >=150 | 1200 |
| DH50 | 450 | <=22 | >=51 | >=20 | >=100 | >=150 | 1100 |
| DH65 | 580 | <=22 | >=51 | >=20 | >=100 | >=150 | 1200 |
| DH75 | 665 | <=22 | >=51 | >=20 | >=100 | >=150 | 1500 |
| DH100 | 890 | <=22 | >=51 | >=20 | >=100 | >=150 | 1500 |
| DH150 | 1335 | <=24 | >=51 | >=25 | >=100 | >=150 | 1800 |
| DH200 | 1780 | <=31 | >=70 | ||||
| DH250 | 2225 | <=31 | >=70 | >=30 | >=140 | >=200 | 2700 |
| DH350 | 3115 | <=37 | >=70 | >=35 | >=140 | >=200 | 3300 |
Product Show:
After-sale Serives
Packing: Wooden case or as clients' request.
Shipping: By sea or by air for exporting goods.
Established in 1998, Cangzhou Lockheed Drilling Equipment Parts Co., Ltd. is a professional technology-oriented enterprise specialized in the production drilling equipments and tools,which is one of the leading
corporations of drilling tools and workover fishing tool manufacturing industry. Including three series with full
model types,as follows:
Drilling Bit series: rock roller bit,tricone bit,pdc drill bit,single bit,cone bit and hole opener;
Drilling Equipment Parts series: manual tong,elevator,slips,stabilizer;
Workover Fishing Tool series: releasing spear,junk basket, overshot,reversing sub,die collar, fishing tap
etc.
Cangzhou Lockheed Drilling Equipment Parts Co., is located at the center of Beijing-Tianjin-Hebei-Shandong-Henan-Region which is adjacent to National Expressway No.106, 166km away from Beijing,110km away
from Tianjin and 35km away from Baiyangdian, the Pearl of Huabei Area. More convenient transport,faster
delivery,and more trustful enterprise is your best choice.Come on,join us.
Our goal:Strive for Perfection and Win by Quality.
How to order the products???
Please send the inquiry with detail item description or with Model number.
If there is no packing demand we take it as sea-way packing.
If possible please attach one reference picture to avoid any misunderstanding or any links from our website for we get a better understanding.
Can I expect a quality products???
Yes. All our activities are accredited to ISO 9001:2008 and API, both in products and services, at the same time, mature production technology ensuring the quality satisfy international request.
All sizes and IADC codes of drill bits are available.
Special requirements of different models can be customized.
Strive for Perfection and Win by Quality!!!
We would like to establish business relations with you !!!
