steel tooth drill bits 12 1/4
1.good wear-resistance
2.higher stability
3.timely delivery
ver all IADC code
1. API Steel tooth drilling bit for Soft Formation
TYPE: G13 (IADC----131)
APPLICABLE FORMATION: Soft Formations with low compressive strength: Clay rock, Gypsum, Shale, soft Limestone, Salt.
HARDNESS OF ROCK: f<2
WEIGHT RECOMMEND: 20-35kg/mm (Dia Bit) (1100-2000 lb/in)
ROTARY SPEED: 80-150rpm.
2. API Steel tooth drilling bit for Medium Formation
TYPE: G23 (IADC----241)
APPLICABLE FORMATION: Hard Sandstone, hard Shale, hard Gypsum, and soft Limestone with low compressive strength
HARDNESS OF ROCK: f<2
WEIGHT RECOMMEND: 20-63kg/mm (Dia Bit) (1100-3500 lb/in)
ROTARY SPEED: 70-80rpm.
3. API Steel tooth drilling bit for Hard Formation
TYPE: G33 (IADC----311)
APPLICABLE FORMATION: Hard sandstone, Granite, Quartzite, abrasive Shale with high compressive strength.
HARDNESS OF ROCK: f 5-8
WEIGHT RECOMMEND: 55-90kg/mm (Dia Bit) (3000-5000 lb/in)
ROTARY SPEED: 50-80rpm.
4. API Steel tooth drilling bit for Hard Formation
TYPE: GHM33 (IADC-----311)
APPLICABLE FORMATION: Hard sandstone, Granite, Quartzite, abrasive Shale.
HARDNESS OF ROCK: f 3-6
WEIGHT RECOMMEND: 20-50kg/mm (Dia Bit) (1100-2800 lb/in)
ROTARY SPEED: 40-60rpm.
Specifications of API steel tooth drilling bit:
Model | TCI Bit, API steel tooth drilling bit |
IADC CODE | 116 117 12 6127 136 137 216 217 226 226 316 317 326 327 336 337 115 125 135 215 225 235 315 325 335 114 124 214 314 111 121 131 346 347 |
417 427 437 517 527 537 617 627 637 737 837 832 415 425 435 445 525 625 635 416 427 436 446 447 516 526 537 547 516 536 535 | |
available sizes: | From 2 7/8 to 26” larger sizes for hole opener bit ,reamer bit |
advantage | most favourable price and best qualtity |
bearing type: | sealed bearing and non-sealed bearing HJ(metal sealed journal bearing) HA (rubber sealed journal bearing aircooled bearing type |
Formation or layer | soft ,medium soft ,hard,medium hard,very hard formation |
Button size (extra features) | Button bit,saw teeth 1) Y-Conical teeth 2) X-chisel teeth 3)K- wide teeth 4)G- Gague protection |
Application | petroleum&gas ,water well ,mining and tectonic industries ,oil field, construction, geothermal, directional boring, and underground foundation work |
Packing: Wooden case or as clients' request.
Shipping: By sea or by air for exporting goods.
Cangzhou Lockheed Drilling Equipment Parts Co., Ltd. is a professional manufacturer of drilling equipments and tools which is located in Hejian City, the centre of the triangle of Beijing, Tianjin and Shijiazhuang, enjoying convenient transportation.
Our products Including below three series with full model types:
Drilling Bit: rock roller bit,tricone bit,pdc drill bit,single bit,cone bit and hole opener;
Drilling Equipment Parts: manual tong,elevator,slips,stabilizer;
Workover Fishing Tools: releasing spear,junk basket, overshot,reversing sub,die collar, fishing tap etc.
Our staff are professional and experienced. By the hard efforts and united cooperation, we have established a wide sale network. Striving for excellent quality, better price and perfect service. Welcome new and old customers to order.
1. How to order the products?
Answer:
Send the inquiry with detail item description or with Model number.
If there is no packing demand we take it as sea-way packing.
If possible please attach one reference picture to avoid any misunderstanding or any links from our website for we get a better understanding.
2. About lead time and shipping time?
Answer :
The lead time depend on quantity of order. Usually shipped by sea, small order or urgent order we can send you by air after received your agreement.
According the distance from china to your port, usually from China to European about 25 days. To West of American 20 days.
3.Can I expect a quality products?
Answer :
Yes. All our activities are accredited to ISO 9001:2008 and API, both in products and services, at the same time, mature production technology ensuring the quality satisfy international request.
Pls do not forget to add below information in your inquiry which will help us to give you the exact quotation at the first time:
1) the size of the tricone bit you need
2) the IADC code of the bit, like 537G
3) the drilling information of the layer
4) quantity
Welcome visit our page, any need pls feel free to contact me.
I'm Bonnie, always at your service!
