Specifications
1.Top professional crane manufacturer in China2.Reasonable price with warranty
3.Excellent performance
4.26 years experience
Weihua crane group has its gear box reducer factory, it not only provides high quality soft gear reducer, semi-harden reducer, and hard gear reducer to domestic customers, but also supplies the above products to overseas customers. We welcome all interested customer to come and have a look.
Hard gear reducer
Model |
Structure trait |
Basic parameters |
Applications |
DABM |
Motor 3in1 |
|
Specially for crane |
H/B |
Grade2, 3, 4 transmissions. Parallel shafts transmission and vertical shaft transmission modularization reducer |
Specification:4,5……26 |
Metallurgy, mine, building material, crane, transport, chemical industry |
F series parallel shafts(3in1) |
Motor, reducer, brake 3in1. Parallel shaft distribution. |
specification:37,47……127 8type speed ratio:i=3.77~153.67 |
Applied for crane travel mechanisms and other transmission mechanism with limited space dimension |
|
K series helical teeth, bevel teeth |
Motor, reducer, brake 3in1. Right angle shaft distribution. |
Specification:37,47……157 9type speed ration:i=5.29~1498.81 |
Applied for crane travel mechanisms and other transmission mechanism with limited space dimension |
PE series lengthen center distance |
Grade3, 4 transmission. V- Vertically mounted without anchor M-Horizontally mounted without anchor. H-Horizontally mounted with anchor |
specification:5,6……22 18type speed ratio:i=14~250 T2=11~470kN.m |
|
QY |
Grade3, 4 transmissions. QYS-3 supporting points with vertical mount or horizontal mount. QYD-Understructure with horizontal mount |
specification:a=160,180……800 |
QY model main applies for crane related travel mechanisms and other transmission mechanism in metallurgy, mine, transport, chemical and light industry. |
|
ZDY/ZLY/ZSY Cylinder gear |
Grade1, 2, 3, transmissions. Involute cylinder teeth, horizontal mount. |
specification:a=80……710mm |
|
|
DBY/DCY Bevel-Helical |
Grade2, 3, transmissions. Involute cylinder teeth, horizontal mount. Arc teeth , bevel teeth and involute cylinder teeth, horizontal mount. |
specification:a=160……800mm |
|
