Cutter Suction Dredger
Product Description
This Hydraulic Cutter Suction Dredger is specially designed for cleaning sediment. Its working flow is that cut and stir the sediment first,then pump the solids to far place through discharge pipe.
Feature of Dreger
1).Cutter Suction Dredger of steel construction,dismountable type,is able to berth and dredge at water both in the coastal area and inland rivers.The dredger can be used to excavate and transport cohesive sediment below the class Ⅲ specified in code for dredging engineering construciton technique issued by Ministry of Water Resources(MWR) of P.R.China.
2).It's hull consiss of a main pontoon and two side pontoons which is easy to dismantle or mount for transportation by road,rail or water and easy to ressemble at project site.
3).The dredger is powered by diesel engines.The main diesel engine driven the dredge pump and auxiliary engine drives hydraulic system including cutter,swing winches,ladder winch and the spud rams etc.
4).The spacious control cabin is ergonomically designed with 360 degree view.All the operation buttons,swift,indicators and gauges are equipped on the control desk.Only two person can operate the dredger in operation room.
5).The dredger is painted by 4 layers of marine paint to protect from the corrosion.The Zinc anode can be used to give better anti-corrosion function.
Application of Hydraulic Cutter Suction Dredger
1).Used for river silt cleaning, sand production and mining project.
2).Suitable for heavy duty operation in tropical climate and sheltered waters.
Technical Parameters
Manufacturer |
WEIHUA |
Type |
HCCSD-300 |
Main Characteristics | |
Side PontoonDimension (L*W*H) |
24m*2.2m*1.5m |
Dredging depth |
13.0m |
Discharging distance |
1500m |
Pump flow |
2000 m3/ h |
Sand output |
200-300 m3/ h |
Pump Suction Diameter |
350mm |
Pump Discharge Diameter |
300mm |
Discharge Pipe Inside Diamter |
Stell pipe or HDPE pipe |
Dredge pump | |
Pump Manufacture |
Shijiazhuang pump |
Model |
14/12G-G |
Pump capacity |
2000 m3/ h |
Head (H) |
45m |
Generator |
|
Power |
30kw |
Certificates
Customer Visits
Weihua group mainly dealing in researching, developing and producing the lifting machinery, port machinery, reducer, etc, and also Weihua Group has become one of the most competitive enterprise group with the largest production and sales volume and the most influential brand in China’s crane industry.
Weihua Group also serves as Deputy Chief Director in the Heavy Machinery Industry Association, Material-handling Association and the Bridge Crane Sub-association of China;
It is also one of the first batches of National Technology Innovation Demonstration Enterprise.
Up to now, our pruducts have been exported to more than 69 countries like America, Japan, Russia, Korea, etc.
After-sales Services
Warranty
WEIHUA grants our clients a twelve-month period or 2000-hour warranty for any products purchased from our company.
Spare Parts
WEIHUA is dedicated to provide our clients with high quality spare parts. With our global distributor network, you are guaranteed with fast deliveries and services, wherever you are.
Installation&Maintenance
WEIHUA is able to provide you with the overall installation of complicated machinery and equipment and inspection of the whole machine, operation equipment.
Training
WEIHUA offers training services to different users. Training programs can be conducted in our factory field, or at the client’s site.
Technical Advice
WEIHUA can also help clients coordinate with trained service personnel to provide you detailed and extensive knowledge about your specific machine.
1. Sales manager cell number is 24hours available.
2. Payment term is flexible.
3. Design the product according to your technical request.
4.Our engineer is willing to help fixing the crane for you.
5. Diversity of products.
6. Delivery on time.
7. Warranty: 12 months.
For more details, please contact us!
This is the overview of our products. For more details, please never hesitate to tell us, we will be pleased to be of further assistance.
