Best buy automatic voltage stabilizer 12v 220v air cooling ferrite core producing price electronic step down transformer
- 300 Set / Sets per Month
- Qingdao Port
- T/T
Product Details
| Place of Origin: | Shandong, China | Brand Name: | Great Wall | Model Number: | S11 |
| Usage: | Power | Phase: | Three | Coil Structure: | Toroidal |
| Coil Number: | Autotransformer |
Product Description
Rated capacity: 10-2500kVA
Voltage combination:
High: 38.5KV 35KV
Low: 0.4kV
Low loss and noisy
Compared with normal oil immersed power transformer has no oil storage box and adopts the corrugations on the oil tank as its heat-radiation parts
Oil tank is made by fine cold-rolled steel on an exclusive production-line
Corrugations can expand or contract according to the change of oil volume
Thus the inner space of transformer can be isolated from the air
which can reduce the aging speed of oil and prevent the insulation materials from damping
Oil-immersed transformer possesses a reliable operation and is free from maintenance
| transformer3150kva | |||||||||||||||
| Loss(kW) | Weight (kg) | (mm) | Gauge | ||||||||||||
| Rated Capacity | Voltage Group(kV) | Connection Method | (75) | No-load current | Impedance Voltage | (L) | (W) | (H) | |||||||
| (kVA) | HV | LV | No-load | Load | % | % | Machine | Oil | Gross | Dimension | Vertical | Horizontal | |||
| 50 | 0.21 | 1.21 | 2 | 195 | 205 | 590 | 1000 | 950 | 1450 | 550 | 550 | ||||
| 100 | 0.29 | 2.02 | 1.8 | 320 | 240 | 790 | 1080 | 1000 | 1600 | 550 | 550 | ||||
| 125 | 0.34 | 2.38 | 1.7 | 395 | 270 | 950 | 1100 | 1030 | 1630 | 660 | 660 | ||||
| 160 | 0.36 | 2.83 | 1.6 | 460 | 285 | 1020 | 1130 | 1060 | 1630 | 660 | 660 | ||||
| 200 | 0.43 | 3.33 | 1.5 | 555 | 325 | 1170 | 1190 | 1060 | 1670 | 660 | 660 | ||||
| 250 | 0.51 | 3.96 | 1.4 | 630 | 340 | 1340 | 1260 | 1160 | 1700 | 660 | 660 | ||||
| 315 | 38.5 | Dyn11 | 0.61 | 4.77 | 1.4 | 720 | 400 | 1530 | 1280 | 1240 | 1790 | 660 | 660 | ||
| 400 | 36.5 | 0.4 | Yd11 | 0.73 | 5.76 | 1.3 | 6.5 | 830 | 490 | 1780 | 1960 | 880 | 1900 | 820 | 820 |
| 500 | 35 | Dyn5 | 0.86 | 6.93 | 1.2 | 930 | 510 | 1960 | 2020 | 940 | 1920 | 820 | 820 | ||
| 630 | 33 | Yyn0 | 1.04 | 8.28 | 1.1 | 1085 | 600 | 2290 | 2070 | 1010 | 2010 | 820 | 820 | ||
| 800 | 1.23 | 9.9 | 1 | 1270 | 660 | 2640 | 2240 | 1040 | 2150 | 820 | 820 | ||||
| 1000 | 1.44 | 12.15 | 1 | 1495 | 735 | 3100 | 2300 | 1200 | 2150 | 820 | 820 | ||||
| 1250 | 1.76 | 14.67 | 0.9 | 1775 | 830 | 3630 | 2450 | 1280 | 2250 | 1070 | 1070 | ||||
| 1600 | 2.12 | 17.55 | 0.8 | 2140 | 935 | 4235 | 2220 | 1510 | 2350 | 1070 | 1070 | ||||
| 2000 | 2.61 | 21.5 | 0.8 | 2535 | 1035 | 4910 | 2310 | 1740 | 2440 | 1070 | 1070 | ||||
| 2500 | 3.15 | 23 | 0.8 | 3140 | 1190 | 5840 | 2370 | 1840 | 2490 | 1070 | 1070 | ||||
| (Note): (Tapping range of high voltage) ±5%; ±2×2.5%. power transformer oil distribution transformer | |||||||||||||||
1. We offer the best solution and products to fulfill the buyers' requirments.
2. We can arrange technicians to install the equipments and train your staff on site.
3. Anytime, we provide considerate technical consultation.
4. Prompt reply for your inquiry and feedback.
