Performance |
1 |
rated loading |
2000kg |
2 |
overall weight |
5800kg |
|
3 |
rated bucket capacity |
1.2m3 |
|
4 |
maximum tractive force |
≥54KN |
|
5 |
maximum breakout force |
≥45.4KN |
|
6 |
maximum grade ability |
30℃ |
|
7 |
maximum dump height |
2630mm |
|
8 |
maximum dump reach |
863mm |
|
9 |
overall dimension (L×W×H) |
5853×2000×2750mm |
|
10 |
minimum turning radius |
4759mm |
|
Engine |
11 |
model |
4BTA3.9—C80 (Cummins) |
12 |
type |
Vertical, in-line, water cooled, 4-stroke diesel engine |
|
13 |
No. of cylinder-bore/stroke |
4—102×120mm |
|
14 |
rated power |
60kw—2000r/min |
|
15 |
maximum torque |
252N.m |
|
16 |
min fuel-consume ratio |
≤240g/kw.h |
|
|
Transmission system |
17 |
torque converter |
YJ—280S2 |
18 |
gearbox mode |
Countershaft power-shift |
|
19 |
gear shift |
2 forward shift 2 reverse shift |
|
20 |
maximum speed |
24km/h |
|
Drive axles |
21 |
main reducing mode
|
Circular Arc Bevel gear, single stage |
22 |
decelerating mode |
Single stage planetary type |
|
23 |
wheel base (mm) |
2250mm |
|
24 |
wheel tread |
1640mm |
|
25 |
ground clearance |
310mm |
|
|
Hydraulic system |
26 |
system working pressure |
16MPa |
27 |
boom lifting time |
4.8s±0.2s |
|
28 |
total time |
9.2s±0.5s |
|
29 |
fuel tank capacity |
80L |
|
30 |
function of leveling automatically |
yes |
|
|
Brake system |
31 |
service brake |
air assist disc brake on 4 wheels |
32 |
parking brake |
flexible shaft operated external drum |
|
|
Tyre |
33 |
type specification |
16/70—20 |
34 |
front tyre pressure |
0.22Mpa |
|
35 |
rear tyre pressure |
0.18Mpa |
a. Delivery term:
We will delivery for you after you done the full payment within 7 to 20 working days.
b. Payment:
Usually,we accept T/T, irrevocable L/C at sight ,for regular order ,we prefer 50% in advance ,50% against the copy of B/L.
Factory & Office environment
Cooperative partner
1.We have a professional and efficient team. Young R&D team with experienced, our team average age is 13 years and the staff longest experience in the industry field are over 15 years while the shortest one are more than 20 years.
2.Our products manufacturing process are in accordance with GB/T19001-2008 quality management system requirements and technical standards are in accordance with GB11022 / DL404 /IEC60694 which could guarantee delivering time & excellent quality for the clients.
3.The price advantage: our company has established complete supplier evaluation & supervision system, strict control of production cost and strive to provide the optimized cost-effective products for clients
4.Professional and timely after-sales service: Based on all products standardized design, we can provide users with the most convenient and fast service, our 24 hours service telephone: 0086-532-80771657.
5.Team trust, cooperation, commitment, loyal customers, strict compliance and deliver on time.
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample but not free.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 70% T/T in advance ,balance before shippment.
