(SS-OV01) hot air cycled industrial electric oven

customs approved wood box, different paking size by different size (SS-OV01) hot air cycled industrial electric oven

SS-OV01 hot air cycled industrial electric oven

Description of SS-OV01 hot air cycle industrial electric oven:
This SS-OV01 hot air cycled industrial electric oven adopts the principle of level wind conveying and is applicable to the drying and warming solid of all parts. It is widely used for drying industries enamel paint, insulation varnish of inductor, insulation varnish of transformer,insulation varnish of motor, insulation varnish of relay, capacitor, toys, hardware, bag glue for leather goods, gypsum products and silicon glue forming etc.

Functions and features of SS-OV01 hot air cycle industrial electric oven:
1. Digital temperature controller, Automatic constant temperature; The work temperature can be set according to the product of requirements.
2. Have the alarm function and over temperature protection.
3. The work time can be set. When the setting time ends, the operation can be stopped automatically.
4. Safe and reliable, convenient operation.

Technical parameter of SS-OV01 hot air cycle industrial electric oven :
1. Overall structure: The outer box is soldered by the conversion of 1.5mm iron boards. The interlayer is filled with 80K chrysotile for heat preservation. The way of wind conveying is level wind conveying.
2. The electric heating system: Use 3-phase 4-line 380V, the total power is about 6KW.
3. Wind conveying system: Motor 3-phase 4-pole 380V, the diameter of fan is 9 inches (powerful multi-wing B direction)
4. The functions of control system include phase, circuit break, short circuit, overloading, over temperature, explosion prevention and environmental protection.
5. Work thermostatic scope: 0º C~250º C (the temperature be made by user's request)
6. Thermal difference: ± 1º C~3º C
7. Inside empty size of oven: L800* W500 *D500mm (the size be made by user's request)
8. The color of machine can be changed.

***** we can customize the high temperature industrial oven according to user's requirements, welcome to inquire*******

Customs approved wood packing box of SS-OV01 hot air cycle industrial electric oven:

Service tenet

Provide you the best service with “fast + satisfactory + safe”.

Warranty period

12 months long after the user received the product.

Warranty items

Only for abnormal breakdown caused by the machine design or manufacture defect,

free repair and accessory will be provided.

Technology service ability

All service engineers with many years experience are gotten special technology training, who can deal with various breakdown problem.

Guide the user to use accurately and how to maintain the product.

Provide free consultation about production process technology of electronic products.

Service after sell

In order to guarantee the machine used normally, we’d have training on how to operate, use and maintain our product by English manual, video, guiding on line.

Use instruction

Apply for the right complete size of product, otherwise, the wrong dimensions will affect the use effect.

Do ensure using the product accord to the use instruction completely.Do not exceed the scope of application of the products.

Maintain the product after use,Damp proof, rust proof, leak proof, explosion-proof, regular maintenance and inspection should

be taken care. All done help to extend the use period.

User document management

Establish perfect user document management in EPR system, Every product running details would be followed to manage.    The users would be taken good care.

About product

1. Product photo: All product photos are taken by real product, There is the color aberration between the product and photo, which is caused by shoot light, product size, manual technology and computer display etc. It’s not quality problem. Parts of products are changed in appearance due to technology revolutionary and process improvement. SanShine would ensure the parameter of product is unchanged, The product couldn’t affect to use.

2.Product size: All parameters are all measured by manual just for reference. There is a small deviation due to the difference of measure tools, lot products and produce process. Real size should be accordance with the final delivery product.

3.Quality inspection: All products should be inspected strictly before shipment. Ensure the good function and appearance.

Package and transport

General package(Paper carton or plastic bag):  For small goods, Package it with form and pack paper to guarantee unbroken during the transport.

Wooden case package: For larger scale goods as machine equipment etc, we have special skilled carpenter, who would make the proper wooden case with exact thickness,density,length. The up arrow ↑marked on the outer wooden case. Buffer material would be put in the wooden case to prevent crack and shock. We will inform you the delivery note. You just need to wait for phone call, then pick up the goods at the nearest logistic station .(Please let me know in advance if you want get the goods at home.)
