SS1000WT gear type Digital Automatic Super big Winding and Taping Machine adopt precision digital toroid controller, it's an accurately and reliability digital automatic toroid-winding machine. it is used for winding thick wire and wraping insulation tape in one time for big toroidal transformer, toroidal current transformer, toroidal coil, toroid choke coil, power inductors, power magnetics, UPS inductor with thick wire, converter inductors with thick wire, heavy toroidal core with heavy wire coils, extra high voltage toroidal transformer, etc.
2. Hi-tech shuttle for highest efficiency.
3. Separate speed controls for loading and winding and taping.
4. Accurately count length of loading by limited-switch.
5. Accurately count turns of winding by photo-electricity sensor.
6. Programmable winding direction, winding returns range (Turns or Angle) and segment winding angle.
7. Accurately wire spacing by adjustable.
9. Memory capacity accommodates 29 sets programes with off-power memory retention. SS1000WT gear type Digital Toroid Winding and Taping Machines adopt precision digital toroid controller, it's an accurately and reliability digital toroid-winding and taping machine.
| Wire diameter | 1.5 -5.0mm | Head number | one winding head and one taping head |
| Insulation tape width | Any dimensions | Max. winding speed | 150 RPM |
| Max. final coil O. D. | Φ700 - 13500mm | Wire spacing | stepping motor |
| Min. final coil I. D. | Φ650mm | Supply voltage | AC220V,50Hz single phase |
| Max. final coil height | 320mm | Mechanical dimensions | 1500*1350*1500mm |
| Controller storage capacity programs | 29(sets) | Weight | denpend on core different size |
How to select the best suited automatic toroid coil winding machine for your toroid coil ?
