Ceramic wire guide pulley

carton for Ceramic wire guide pulley

  Ceramic wire guide pulley

Description of ceramic guide pulley(Ceramic wire roller) :

Ceramic wire guide pulley(wire roller) is used for the direction change and the guidance of the enameled wire. The ceramic circle inside is made by the fine porcelain. There is a high-speed bearing in the ceramic circle which can assure the lag sliding distance between the wire and the circle is no more than 0.2mm, thus the wire insulation film has been protected and the beating of the wire has been controlled within a certain small scope in good. The sidewalls of the ceramic roller can prevent the jump of the wire during the winding, and stabilized the tension.

Features of  Ceramic wire guide pulley (Ceramic wire roller):

1.The surface polish degree of the porcelain ring : Ra0.2.

2.The sliding distance between enameled wire and the roller :≤0.2mm

3.The hardness : HRa88.

Specification of  Ceramic wire guide pulley (Ceramic wire roller) (refer above measurements drawing):

Pictures of Ceramic wire guide pulley

Service tenet

Provide you the best service with “fast + satisfactory + safe”.

Warranty period

12 months long after the user received the product.

Warranty items

Only for abnormal breakdown caused by the machine design or manufacture defect,

free repair and accessory will be provided.

Technology service ability

All service engineers with many years experience are gotten special technology training, who can deal with various breakdown problem.

Guide the user to use accurately and how to maintain the product.

Provide free consultation about production process technology of electronic products.

Service after sell

In order to guarantee the machine used normally, we’d have training on how to operate, use and maintain our product by English manual, video, guiding on line.

Use instruction

Apply for the right complete size of product, otherwise, the wrong dimensions will affect the use effect.

Do ensure using the product accord to the use instruction completely.Do not exceed the scope of application of the products.

Maintain the product after use,Damp proof, rust proof, leak proof, explosion-proof, regular maintenance and inspection should

be taken care. All done help to extend the use period.

User document management

Establish perfect user document management in EPR system, Every product running details would be followed to manage.    The users would be taken good care.

About product

1. Product photo: All product photos are taken by real product, There is the color aberration between the product and photo, which is caused by shoot light, product size, manual technology and computer display etc. It’s not quality problem. Parts of products are changed in appearance due to technology revolutionary and process improvement. SanShine would ensure the parameter of product is unchanged, The product couldn’t affect to use.

2.Product size: All parameters are all measured by manual just for reference. There is a small deviation due to the difference of measure tools, lot products and produce process. Real size should be accordance with the final delivery product.

3.Quality inspection: All products should be inspected strictly before shipment. Ensure the good function and appearance.

Package and transport

General package(Paper carton or plastic bag):  For small goods, Package it with form and pack paper to guarantee unbroken during the transport.

Wooden case package: For larger scale goods as machine equipment etc, we have special skilled carpenter, who would make the proper wooden case with exact thickness,density,length. The up arrow ↑marked on the outer wooden case. Buffer material would be put in the wooden case to prevent crack and shock. We will inform you the delivery note. You just need to wait for phone call, then pick up the goods at the nearest logistic station .(Please let me know in advance if you want get the goods at home.)
