mr16 led 8W spotlight dimmable , 12VDC/AC, retrofit 50W halogen totally, 50000 hrs lifetime with genuine NICHIA LED
Application:
Area: Indoor use only.
Purpose: Accent lighting.Local liging.
Product Features:
Product Features:
Adopting GENUINE NICHIA LED, lumens of natural white up to 700Lm,and of warm white up to 600 Lm.
Its form-factor guarantees a 100% form-fit on the back-side of the lamp(exact form fit with halogen lamps)
Delivers a beam intensity which reaches that of a 50W halogen lamp. That it can replacement for 50W halogen lamp directly.
Dimmable down to 15% with most of trailing edge dimmers, when in conjunction with recommended electronic transformers.0-100% dimmable with PWM or 0-10V dimmer.
It uses an active power factor correction structure to control the input current, so that the PFC can reach over 0.95 when in conjunction with electronic transformer.
Specification:
Model Number |
D5007-H2-DIM-MR16(WW) |
D5007-H2-DIM-MR16(NW) |
Power Consumption |
8W |
8W |
LED |
NICHIA |
NICHIA |
Efficiency(lm/W) |
75lm/W |
87.5lm/W |
Color Temperature |
2400K±100K, 2700±100K, 3000±100K |
4000±200K,5000±200K |
Beam Angle |
36° / 60° |
36° / 60° |
Input Voltage |
12VDC/AC |
12VDC/AC |
Working Temperature |
-5°C~+35°C |
-5°C~+35°C |
Base Type |
MR16 |
MR16 |
Dimension(mm) |
φ49.8×58 |
φ49.8×58 |
Net Weight |
62g |
62g |
Lifetime(hr) |
50000 |
50000 |
Packaging information:
Packing: 100 boxes / carton | ||
Box |
52×52×70(mm) |
79g |
Carton |
46×29×24(cm) |
9.1kg |
Optical Performance:
Model Number |
Beam Angle |
Color Temperature |
Light Intensity |
Lumens |
CRI |
D5007-H2-DIM-MR16(WW) |
36° |
3000±100K |
1210cd |
600 |
85 |
D5007-H2-DIM-MR16(NW) |
36° |
5000±200K |
1290cd |
700 |
85 |
D5007-H2-DIM-MR16(WW) |
60° |
3000±100K |
450cd |
520 |
85 |
D5007-H2-DIM-MR16(NW) |
60° |
5000±200K |
510cd |
600 |
85 |
