Home > Lights & Lighting > LED Interior Lighting > LED Spotlight > COB 6.5Wgu10 Led Spotlight Nichia Led Design Lamp,led Manufacturers,dimmable

COB 6.5Wgu10 Led Spotlight Nichia Led Design Lamp,led Manufacturers,dimmable

COB 6.5Wgu10 Led Spotlight Nichia Led Design Lamp,led Manufacturers,dimmable thumbnail-1
COB 6.5Wgu10 Led Spotlight Nichia Led Design Lamp,led Manufacturers,dimmable photo-1
US$ 15 - 17 MOQ: 100 Pieces
Key Specifications
Get Latest Price
LED Light Source:
nichia
Lamp Power(W):
6.5
Lamp Luminous Flux(lm):
500
Contact Supplier Request Quote Chat Now
Shanghai Winsun Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source nichia
Lamp Power(W) 6.5
Lamp Luminous Flux(lm) 500
Lamp Luminous Efficiency(lm/w) 77
Color Temperature(CCT) Other, warm or natural
Working Temperature(℃) -5, 35
Working Lifetime(Hour) 40000
Lamp Body Material Aluminum
Certification CE, EMC
Base Type GU10
Place of Origin Shanghai, China
Brand Name Winsun
Model Number SP1604-COB-DIM-GU10








6.5W COB gu10 dimmable led spot light ,NICHIA LED CE ROHS SAA

Product feature



      Adopting LUMINUS COB LED delivers a uniform luminance.

      High CRI 85. Models with CRI 95 also available which makes colors look vibrant and especially rich.

      Extremely high efficiency of the driver up to 90%. Lumens of natural white up to 600lm, and of warm white up to 630lm.

      Perfect dimmable down to 5% with most trailing edge and leading edge dimmers and dimming systems.

      Unique soft start when connecting with trailing edge dimmer protect and comfort your eyes well.




Model Number

Power Consumption

LED

CRI

Efficiency

(lm/W)

Color Temperature

Beam Angle

Input Voltage

PFC

Light

Intensity

Lumens

Dimmable

SP1604-COB-DIM-GU10(WW)

6.5W

LUMINUS

85

73

2700±200K  3000±200K

24°

220-240VAC

>0.9

1630 cd

480 lm

YES

SP1604-COB-DIM-GU10 (NW)

6.5W

LUMINUS

85

77

4000±200K  5000±200K

24°

220-240VAC

>0.9

1720 cd

500 lm

YES

SP1604-COB-DIM-GU10(WW)

6.5W

LUMINUS

85

73

2700±200K  3000±200K

36°

220-240VAC

>0.9

920 cd

480 lm

YES

SP1604-COB-DIM-GU10 (NW)

6.5W

LUMINUS

85

77

4000±200K  5000±200K

36°

220-240VAC

>0.9

930 cd

500 lm

YES




COB 6.5Wgu10 led spotlight nichia led design lamp,led manufacturers,dimmable



General characteristics



Model Number

Product name

Material

Base Type

IP Rating

Dimension

(mm)

Net Weight

Lifetime

(hr)

Working Temperature

SP1604-COB-DIM-GU10(WW)

LED Spot GU10

Aluminum

GU10

IP20

Φ49.8x60

62g

40000

-5℃~+35℃

SP1604-COB-DIM-GU10(NW)

LED Spot GU10

Aluminum

GU10

IP20

Φ49.8x60

62g

40000

-5℃~+35℃







COB 6.5Wgu10 led spotlight nichia led design lamp,led manufacturers,dimmableCOB 6.5Wgu10 led spotlight nichia led design lamp,led manufacturers,dimmableCOB 6.5Wgu10 led spotlight nichia led design lamp,led manufacturers,dimmable
