Welcome,my friend! Glad to introduce our company Hugong Group to you.
Our company produce proximity Sensor, magnetic sensor,position sensor,
infrared sensor,photoelectric sensor,switching power supply and etc.
If you have any questions, please don't hesitate to ask me.
The specification of our Newest Products.
| Dimension | 38*62*100mm | ||||||
| Dimensional drawing | |
||||||
| Model | BZJ-311G |
BZJ-311B | BZJ-311W | ||||
| light source | green |
blue | white |
||||
| Output Type | NPN, PNP, analog output | ||||||
| Output Time |
50us |
||||||
| Detection distance |
10mm ± 2mm |
||||||
| Switching output current |
<200mA |
||||||
| Switching output level | Low (pass): <1.5V, high level (off): Power supply voltage -0.7 (RL = oc) | ||||||
| Supply voltage and current | 10—30VDC, <80mA | ||||||
| Protection | Power reverse protection, load protection, short circuit protection. | ||||||
| working environment | Temperature: 0-50 ℃, sunshine <10000Lux | ||||||
| Dimensions | 38 (w) * 62 (H) * 100 (L) mm, wire 2m | ||||||
Installation
Applications legend
What type of sensor do you need? You need to consider the following factors:
Detected object |
magnetic metal |
inductive proximity sensor |
conventional object |
capacitive proximity sensor |
|
photoelectric sensor | ||
Detecting range |
less than 50mm |
proximity sensor |
greater than 50mm |
photoelectric sensor |
|
Detection mode |
magnetic |
hall effect sensor |
reed sensor | ||
infrared |
photoelectric sensor |
|
Installation dimension |
cylindrical |
cylindrical type |
square |
square type |
|
groove |
groove type |
|
Connection |
cable |
cable type |
connector |
connector type |
There are other factors like current,voltage,housing material,accessory and so on.If you are confused on choosing a right type of sensor, please contact us without hesitation.
Our Group introduction
1.With 10 years specializing in producing sensor selection manual,solid state relay,switching power supply
selection manual.
2.After years of development, the company has created a wealth of experience in sales and after-sales service team.
3.Strong enterprise innovation,with groups of professional engineers and salesman.
4.Our high quality have gain the market public praise from domestic.
5.We have very good and comprehensive after sales service.
6.We have no MOQ for client.
7.Manufacturers and users in the formation of a very high reputation.
1. Q: What certifications do you get?
A: We have CE.
2. Q: Are OEM&ODM available?
A: Yes, we accept OEM and ODM.
4. Q: How to pay?
A: T/T,PayPal and western union are acceptable.Full payment by T/T before shipment. Trade term:FOB CIF CNF DDP
5. Q: What is the delivery time?
A: Generally, 3-5 working days after the payment.We have the normal type on stock and we can make the delivery
within 3 days.If the customer has the special requirements,delivery time depends on the quantity ordered.
6. Q: What about the Package?
A: Standard export package (paper carton) for shipment with our company’s brand.Inner box with 10pcs products
sealed package.All of the productions are inspected carefully by QC before delivery.
7.Q:What is your company min.order?
A: No MOQ for stocking production.
Order a HQ container,price will be more favorable.
