Wholesale 150Mbps USB2.0 Wireless Lan 802.11N
1. Interface USB 2.0
2. Standards IEEE 802.11b/g/n
3. Data Transfer Rates 11/54/135/150Mbps
4. Antenna Type on board Antenna
5. Wireless Range Indoor/Outdoor(100/300Meters)
6. Transmit Power 17dBm
7. Frequency Range 2.4 - 2.485GHz
8. Network Configuration Ad-Hoc (Peer-to-Peer), Infrastructure
9. Dimensions 61mm L x 21mm W x 7mm H
10. Equipped with an elegant and stylish USB Cradle for flexible deployment
11. specifications:
Wireless Standards |
IEEE 802.11n (draft) IEEE 802.11g IEEE 802.11b |
Host Interface |
High speed USB2.0/1.1 interface |
Data Rate |
802.11n: up to 150Mbps (downlink) and 150Mbps (uplink) 802.11g: 54 / 48 / 36 / 24 / 18/ 12 / 9 / 6 Mbps auto fallback 802.11b: 11 / 5.5 / 2 / 1 Mbps auto fallback
|
Frequency Band |
2.4GHz ISM (Industrial Scientific Medical) Band |
Chipset |
Realtek |
RF Frequency |
2412 ~ 2462 MHz (North America) 2412 ~ 2472 MHz (Europe) 2412 ~ 2484 MHz (Japan) |
Radio Channel |
1 ~ 14 channels (Universal Domain Selection) |
Range Coverage |
Up to 3 times farther range than 802.11g |
Antenna type |
Integrated Antenna |
Roaming |
Full mobility and seamless roaming from cell to cell |
RF Output Power |
13 ~17 dBm (Typical) |
Modulation |
11n: BPSK, QPSK, 16QAM, 64QAM with OFDM 11g: BPSK, QPSK, 16QAM, 64QAM, OFDM 11b: DQPSK, DBPSK, DSSS, CCK |
Data Security |
64/128-bit WEP Encryption WPA, WPA-PSK, WPA2, WPA2-PSK. TKIP/AES |
Network |
Auto-switch to use 802.11n or 802.11g or 802.11b mode Supports Ad-Hoc, Infrastructure WLAN network Wireless roaming Data rate auto fall-back under noisy environment or longer range distance Site Survey with Profile function |
Configuration & Management |
Plug-and-Play setup and installation Management Utility supports 2000 / XP/ Vista |
Media Access Control |
CSMA/CA with ACK |
LED Indicator |
Link/Active ( Green ) |
Operating System |
Windows 2000, XP 32/64-bit, Vista 32/64-bit, |
Environment |
Operating Temperature: 0oC to 40oC Storage Temperature: -20oC to 75oC Operating Humidity: 10% ~ 90% (Non Condensing) Storage Humidity: 5% ~ 95% (Non Condensing) |
Compliant |
FCC (USA) CE Mark (Europe) RoHS Compliant Wi-Fi Compliant |
