Specifications
1.It is used in flat position2.horizontal fillet welding.
3.ISO9001
--Description
YC-E70C-6M efficient metal cored wire uses mixed gas shielded welding , It has excellent anti-hole performance and little slag. You don’t need cleaning the welding slag for welding three times continuously. It is Suitable for high current welding, the deposition efficiency is up to 95-97% , the deposition rate is higher than solid welding wire by 20%. It can be used for automated or semi-automated welding.
--Application
It is used in flat position and horizontal fillet welding. It is suitable for welding the steel of coating with inorganic zinc primer, and used for welding of same grade of steel.
--Chemical Composition of deposited metal (%)
Item |
C |
Mn |
Si |
P |
S |
Standard |
≤0.18 |
≤1.75 |
≤0.90 |
≤0.03 |
≤0.03 |
Test |
0.04 |
1.50 |
0.35 |
0 .013 |
0.009 |
--Mechanical Properties Of Deposited Metal
|
Rm(MPa) |
Rp(MPa) |
A5(%) |
Akv(J)(-200C) |
Standard |
≥480 |
≥400 |
≥22 |
≥27 |
Test |
550 |
480 |
27 |
60 |
--Recommended Current (DC+) and Voltage Range
Shielding Gas: 25% CO2 and 75% Ar
Dia.(mm) |
1.2 |
1.4 |
1.6 |
Gas flow(L/min) |
Flat |
150-300A |
170-400A |
200-450A |
15-25 |
horizontal |
180-300A |
200-350A |
270-400A |
15-25 |
0.45kgs/spool, 0.9kgs/spool, 1kgs/spool: 40spools / box, 32boxes/ pallet
5kgs/spool : 5kgs/carton, 200cartons/pallet
15kgs/spool :72cartons/pallet, 22pallets/20'container
One spool is vacuum packed by aluminum film and then one carton outside
free samples for you all.
New-Type Welding Materials Co., Ltd of Yichen Group specializes in researching and manufacture of flux cored wire. It provides complete series of flux cored welding wire products with consistent quality, excellent performance and perfect process tunability to our customers with different welding purposes, which including shipbuilding, machinery processing, steel-structure construction, metallurgical parts,bridge-building,pressure-resistance containers and pipeline used in oil and chemical industry The main products have been approved by CCS, ABS, DNV, LR, GL, BV, NK, KR, RINA,RS ship classification society. The capacity is 50000 ton/year. Since the consistent quality and good performance, the products have been sold to many countries, which including North American, Europe, Middle East and Asia-Percific. We also established our US branch in 2008,Yichen Sunrise USA,Inc. in phoenix of Arizona,to support our customers in North America market.
