Specifications
E70C-6M WELDING WIREsmooth stable arc transfer, spatter free, excellent bead contour, with a high deposition rate and...
Flux cored welding wire E70C-6M
--Specification conformance
AWS E70C-6M
--Description and using scope
E70C-6M is metal-cored flux cored wire. It has a smooth stable arc transfer, spatter free, excellent bead contour, with a high deposition rate and nearly free of slag weld bead. Used in flat position and horizontal fillet welding. This metal cored wire may be used on welding mild steel and low alloy steel, such as ship, steel structure and bridge.
--Shielding gas :Ar 75% + CO2 25%
--Chemical Composition of deposited metal (%)
Item |
C |
Mn |
Si |
P |
S |
Ni |
Mo |
Cr |
V |
|
0.06 |
1.34 |
0.32 |
0.012 |
0.01 |
/ |
/ |
/ |
/ |
--Mechanical Properties Of Deposited Metal
Item |
Yield Point (MPa) |
TensileStrength (MPa) |
Elongation δ5 (%) |
Charpy V-notch Impact Toughness |
||
|
Test Temp. (°C) |
Impact Energy (J) |
Average (J) |
||||
|
480 |
570 |
29 |
-20 |
130 |
/ |
--Size and Recommended Current (DC+) and Voltage Range
Size |
Voltage Range |
Current (DC+) |
Ar/CO2 flow(L/Min)
|
1.2mm |
25~32 |
200~350 |
15~25 |
1.6mm |
25~35 |
220~400 |
15~25 |
