Gas Protect Hardfacing Welding Wire (mine Fan)

FOB Price

US$ 5.9 - 11.8 / Kilogram

1000 Kilograms(Min. Order)

Port TIANJIN or any chinese port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China	Brand Name	YICHEN
Model Number	YC-ZG100	Material	Other, steel
Diameter	1.6mm	Melting Point	Standard
Weight	15kgs/25kgs	Application	YC-ZG100 used for hardbanding of drill pipes
Flux Content	100%CO2

Product Description

Specifications

YC-ZG100 used for hardbanding of drill pipes

1. Specification

Hard Facing Flux Cored Wire For hardbanding of drill pipes YC-ZG100

2.Description

YC-ZG100 is a kind of metal powder type flux cored wire. It has stable arc, less spatter and excellent appearance .The surfacing hardness of welding is uniform and stable. It adopts Cr-Mn-Mo alloy system.

3.Chemical Composition of Deposited Metal (%)

Standard(%) :C≤1.0 ,Si≤1.5,Mn≤1.5,Cr:5.00-8.00, Other≤3.0

4.Mechanical Properties of Deposited Metal

Hardness:HRC55-59

5. Characteristics

1) Non-cracking

2)Surfacing hardness: HRC55-59.

3)Delivering both adequate tool joint protection and excellent casing wear protection

4)To be compatible with other flux cored wire for drill pipe

hardbanding,such as Anrco 100XT brands,etc .

Re-application without previous removal

5) Can be used for new or old drill pipe with different sizes

6) Used for drill pipe, heavy weight drill pipe, drill collars, centralizers, shock absorbers, and various other downhole tools.

7) Loss of quality wear coefficient by Dry / rubber wheel abrasion test: 0.28%.

6.Available Diameter

1.6MM

7.Package

15kgs/spool, 25kgs/spool

8.Approvals:

ISO9001

9.Shielding gas

100%CO2

10.Recommended Current (DC+) and Voltage Range

Size	Voltage Range	Current (DC-)	CO₂Flow(L/min)
1.6MM	20~30V	200~300A	15~25

Recommended best practices for the voltage: 29V; Current: 250A
