RF Wireless Synchronization digtial strip LED controller with Madrix software,rgb led strip controller,
Introduction:
- YM-H804TC is a RF Wireless Synchronization system, it is composed of sender controller (YM-H804TC-H), receiver controller(YM-H804TC-R), and slaver controller(YM-H801RA). Under our own software LEDBuild, customers can realize many display effects, can play text, picture and video.
- YM-H804TC-H send Synchronization to receiver controller, YM-H804TC-R, and YM-H804TC-R drive the slaver controller to controller led pixel lights to display effects customers programmed. Each YM-H804TC-R can control 122,880 pixels light max. Customer can use YM-H804TC-R as many as he needs. no quantity is limited within the wireless range of sender controller, YM-H804TC-H.
System Composition:
This led control system is composed of Four parts:
1. RF Wireless Synchronization sender- Sender master led controller, it sends out RF wireless synchronization signal to master led controller, YM-H804TC-R.
2. YM-H804TC-R- Receiver master led controller, receive RF wireless synchronization signal. It has two output ports, totally can drive 96pcs of slaver controller, which can be connected to Port 1 or Port2, or Port1 and Port2. One master can control 122,800pixels totally
3. Slaver LED controller - YM-H801RA, has four output ports, each slaver can control 3412 pixel lights Max.
4. LEDBuild—Installed on computer, program display effects of lights, transfer data to SD card then to put in master controller to playback to led pixel lights.
System Composition:
This led control system is composed of Four parts:
1. RF Wireless Synchronization sender- Sender master led controller, it sends out RF wireless synchronization signal to master led controller, YM-H804TC-R.
2. YM-H804TC-R- Receiver master led controller, receive RF wireless synchronization signal. It has two output ports, totally can drive 96pcs of slaver controller, which can be connected to Port 1 or Port2, or Port1 and Port2. One master can control 122,800pixels totally
3. Slaver LED controller - YM-H801RA, has four output ports, each slaver can control 3412 pixel lights Max.
4. LEDBuild—Installed on computer, program display effects of lights, transfer data to SD card then to put in master controller to playback to led pixel lights.
5. Control system realize RGB 256 scales per color, can make more than 16.7M kinds color, for ICs with Enable, can reach 65536 levels.
6. Master-slaver distribution: excellent adjustability to various projects, easy to operate.
7. Support SD card max to 2GB, and can play 32 files of DAT format max.
8. Playing speed is adjustable from 1 to 50 frames/s, and Brightness from 1 to 15.
9. Perfect compatible with DMX512(1990) international standard protocol.
10. Accord with EMC electromagnetism compatibility, good anti-jamming capacity.
Conjunction:
Application:
G&G Technology Co., Ltd. is a leading led lighting solution provider in China, own its GG and YM brands, design and manufactures a wide range of Lighting products,LED light, LED display, LED stip,LED control system, LED module, LED point source pixel,LED drivers, Power supply, and can design and delelop lighting solution per customer's requirement. Our spacious factory is equipped with the latest manufacturing equipment and first-class research and development technology, enabling us to provide high-quality products.
1.Manufacturer with our competitive price
2.Excellent management and technology QC Depa.aftersale team,we can do high technology
aftersale service.good quality products.
3.Prompt response to your request,
4.Short delivery,
5.Reliable warranty
6.OEM/ODM
7.GG and YM brand get the good repulation from all over the world
1.Payment methods:T/T,Western Union
100% payment if the total amount less than 5000USD
30% deposit and 70% balance before shipment if the total amount is more than 5000USD
2.Lead time:3-5 working days,subject to the order quantity
3.Delivery ways:DHL,EMS,UPS,FedEx door to door service,by sea, air and etc
4.MOQ:No quantity limit for the trial order
