Ws2801/ws2812b Ws2821 /tm1812 /lpd6803 / Flexible DMX Rgb Led Digital Strip Addressable Pixel Waterproof Strip

Shenzhen G&G Technology Co., Ltd.
Ws2801/ws2812b Ws2821 /tm1812 /lpd6803 / Flexible DMX Rgb Led Digital Strip Addressable Pixel Waterproof Strip thumbnail-1
Ws2801/ws2812b Ws2821 /tm1812 /lpd6803 / Flexible DMX Rgb Led Digital Strip Addressable Pixel Waterproof Strip thumbnail-2
Ws2801/ws2812b Ws2821 /tm1812 /lpd6803 / Flexible DMX Rgb Led Digital Strip Addressable Pixel Waterproof Strip photo-1
Ws2801/ws2812b Ws2821 /tm1812 /lpd6803 / Flexible DMX Rgb Led Digital Strip Addressable Pixel Waterproof Strip photo-2
US$ 1 - 9 MOQ: 200 Pieces
Key Specifications
Get Latest Price
LED Light Source:
smd5050
Type:
Flex LED Strips
Input Voltage(V):
24
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source smd5050
Type Flex LED Strips
Input Voltage(V) 24
Lamp Power 15
Lamp Luminous Flux(lm) 180
Color Temperature(CCT) rgb
Working Temperature(℃) -25, 45
Working Lifetime(Hour) 50000
Lamp Body Material PVC
Certification CE, FCC
Emitting Color Changeable
Place of Origin Guangdong, China
Brand Name GG
Model Number GG-SF5012S60P-10IC-DMX



Product Description

DC12V DMX512 Video effect addressable rgb led pixel strip, 30/60pcs 5050  DMX led strip light,  dmx rgb led strip light,

every 3/6 LEDs can be controlled individually.  DMX rgb led digital strip,



Parameter and Specification:

Item numberGG-SF5012S30P-10IC-DMXGG-SF5012S60P-10IC-DMX
LED typeRGB SMD 5050 RGB 3-IN-1
LED quantity30pcs/m60pcs/m
DMX Channels/m30channels/meter (10pixels)
VoltageDC12VDC24V
Power Consumption7.6W/m15W/m
IC typeDMX512
ColorRGB
DMX address Set by DMX Writer
PCB Width12mm
Length5m/roll (custom-made available
IP gradeIP20/IP65/IP67/IP68
Working temperature-40°C~60°C
Viewing angle≥140°
LifespanMTBF≥50000h



Application:

This LED strip, as a led pixel point source lights, is suitable for digital led colorful characters, spurts draws, channel letters, blister words, various kinds of light source of illumnation facility. Especally for outdoor use of buildings.

ws2801/ws2812b ws2821 /tm1812 /lpd6803 / flexible DMX rgb led digital strip addressable pixel waterproof strip

ws2801/ws2812b ws2821 /tm1812 /lpd6803 / flexible DMX rgb led digital strip addressable pixel waterproof strip



led accessory:

1.on-line controller work with computer:

ws2801/ws2812b ws2821 /tm1812 /lpd6803 / flexible DMX rgb led digital strip addressable pixel waterproof strip

2.off line controller:

ws2801/ws2812b ws2821 /tm1812 /lpd6803 / flexible DMX rgb led digital strip addressable pixel waterproof stripws2801/ws2812b ws2821 /tm1812 /lpd6803 / flexible DMX rgb led digital strip addressable pixel waterproof strip



3.led drive:

Waterproof

ws2801/ws2812b ws2821 /tm1812 /lpd6803 / flexible DMX rgb led digital strip addressable pixel waterproof strip

Non-waterproof

ws2801/ws2812b ws2821 /tm1812 /lpd6803 / flexible DMX rgb led digital strip addressable pixel waterproof strip





Company Information

G&G Technology Co., Ltd. is a leading led lighting solution provider in China, own its GG and YM brands, design and manufactures a wide range of Lighting products,LED light, LED display, LED stip,LED control system, LED module, LED point source pixel,LED drivers, Power supply, and can design and delelop lighting solution per customer's requirement. Our spacious factory is equipped with the latest manufacturing equipment and first-class research and development technology, enabling us to provide high-quality products.

 ws2801/ws2812b ws2821 /tm1812 /lpd6803 / flexible DMX rgb led digital strip addressable pixel waterproof stripws2801/ws2812b ws2821 /tm1812 /lpd6803 / flexible DMX rgb led digital strip addressable pixel waterproof stripws2801/ws2812b ws2821 /tm1812 /lpd6803 / flexible DMX rgb led digital strip addressable pixel waterproof strip







Our Services

1.Manufacturer with our competitive price

2.Excellent management and technology QC Depa.aftersale team,we can do high technology

   aftersale service.good quality products.

3.Prompt response to your request,

4.Short delivery,

5.Reliable warranty

6.OEM/ODM

7.GG and YM brand get the good repulation from all over the world





FAQ

1.Payment methods:T/T,Western Union

100% payment if the total amount less than 5000USD

30% deposit and 70% balance before shipment if the total amount is more than 5000USD

2.Lead time:3-5 working days,subject to the order quantity

3.Delivery ways:DHL,EMS,UPS,FedEx door to door service,by sea, air and etc

4.MOQ:No quantity limit for the trial order
