5-200Ton per Day Turnkey Wheat Flour Mill Plant
- Shanghai Qingdao Tianjin
- T/T Money Gram
You May Like
Product Details
| Condition | New | Place of Origin | Henan, China | |
| Brand Name | GEMCO | Model Number | Wheat Flour Milling Machine | |
| Production Capacity | 10-100t/daily | Voltage | 380v, 3phase , 50hz | |
| Power(W) | above 40kw | Weight | 640kg,670kg,700kg | |
| Dimension(L*W*H) | 980 * 550 * 1276 | Certification | CE | |
| Warranty | 1year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
5-200Ton per day Turnkey Wheat Flour Mill Plant
The process of turning grain such as wheat, corn etc. into flour is called flour milling. Find out this knowledge could help you start a business of flour mill plant.
If your business is simple and initial investment is limited, 40-60TPD flour mill plant is right for you, it is steel frame construction, low cost. But if you intend to large scale supply of flour, you would have to take care of 80-250TPD or 300-500TPD complete flour mill plant . It occupies larger land spaces to build the plant workshop.
- Single Flour Milling Machinery
- Small Flour Mill Machinery from 10TPD to 30TPD
- Complete Set of Flour Mill Machinery 30-160TPD
The Main Technical Parameters of flour milling machine:
1. Output: 50T per day.
2. The quality of the flour: Conform the stipulation of China GB 1355-864'
3. The total power: 157.95KW
4. Power consumption per ton wheat: 60.65KW*h
5. The voltage: 380V*50HZ.
6. Weight: about 50 ton
7. Bulk: 160M3
The Main Equipment list
The part of cleaning | The part of Marking flour | ||||
No | The name and specification of equipment | QTY | No | The name and specification of equipment | QTY |
1 | PH-50 grain separator | 3 | 1 | 6F-35 flour milling machine | 3 |
2 | DMW-30*60 style scourer | 2 | 2 | GFY-200 style air-lock | 2 |
3 | QSX-56 style sucking stoner | 2 | 3 | 150 style auger | 2 |
4 | Magnetic separator | 1 | 4 | FSFJ2*13*83 plansifter with two nest of sieve | 1 |
5 | FZSH damper | 1 | 5 | 6-30-7# style high pressure fan | 1 |
6 | 4-72-11 style low pressure fan | 2 | 6 | Bagging-box | 2 |
7 | 150 style auger | 4 | 7 | Pneumatic system of making flour | 4 |
8 | Four-cyclone | 1 | 8 | 30 style bran sieve | 1 |
9 | Bucket elevator | 4 | 9 | TBCM-39b pulse cloth pot dust filter | 4 |
The layout of the flour milling plant workshop
1. The total area of the workshop is about 435.2 square meters, (27.2*8*2 two storeys).
2. The total length of the rollers is: 35*12=420cm.
3. The volume of adding the water: depending upon the moisture content of raw wheat, usually temper to 3% moisture, it needs 1.5T water in 24 hours.
What is the process of wheat flour mill?
1.Storage section -----Grain silo (if need)
2.Cleaning section ------(Vibrating Separator | Gravity Grading Destoner | Rotary Flat Sifter | Horizontal Wheat Scourer| magnetic Separator, etc.)
3. Milling section -----(Pneumatic Roller Mill | Plansifter (Single bin or double bin or high square)| Purifier | Dampener | Impact Detacher, etc.)
4. Packing section -----(Flour packing machine | stacking )
With years professional experience and enterprising spirit in grain processing and flour mill plant building, we are confident to help you settle any problems met in your working and ready offering a best and most economical solution for you.
