Home > Manufacturing & Processing Machinery > Agricultural Machinery > Feed Processing Machinery > 1-15 Ton per Hour Pellet Machine Animal Feed

1-15 Ton per Hour Pellet Machine Animal Feed

Name: 1-15 Ton per Hour Pellet Machine Animal Feed
Brand: GEMCO
SKU: 105134191

1-15 Ton per Hour Pellet Machine Animal Feed thumbnail-1

1-15 Ton per Hour Pellet Machine Animal Feed thumbnail-2

1-15 Ton per Hour Pellet Machine Animal Feed thumbnail-3

1-15 Ton per Hour Pellet Machine Animal Feed photo-1

1-15 Ton per Hour Pellet Machine Animal Feed photo-2

1-15 Ton per Hour Pellet Machine Animal Feed photo-3

US$ 10,000 - 100,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

China

Brand Name:

GEMCO

Contact Supplier Request Quote Chat Now

Anyang Gemco Energy Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

CMP

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin China

Brand Name GEMCO

Model Number Pm25, 35, 42, 508

Type Feed Pellet Machine

Voltage 380V

Power(W) 60kw,90kw,110kw

Certification ISO9001, CE

Warranty 1 year Not including the wearing parts

After-sales Service Provided Engineers available to service machinery overseas

Pellet Machine Animal Feed

Our pellet machine for animal feed has very mature technology to make poultry & animal feeds such as fish, chicken, cattle, etc. We have sold many complete poultry feed pellet making line in the domestic market until now. Any potential and serious customer is welcomed to be our present customers.

Main technical parameters of the pellet machine animal feed:

Model	Power(kw)	Yield(ton/h)	Dimension (LWH)(mm)	Net Weight(kg)
PM350	Feeder 0.75	3-5	245010002300	1990
	Conditioner 5.5
	Force Feeder 0.55
	Main Motor 55
PM420	Feeder 0.75	6-8	320011002850	2430
	Conditioner 5.5
	Force Feeder 0.55
	Main Motor 90
PM520	Feeder 0.75	8-15	330012502550	3500
	Conditioner 5.5
	Force Feeder 0.55
	Main Motor 75*2
PM650	Feeder 3 (Frequency Controllable)	10-20	390015002800	4900
	Conditioner 7.5
	Force Feeder 1.5
	Main Motor 110*2

Feature

This model uses double motor SPB strong narrow belt transmission system, has ideal transmission efficiency, rotation steady, output high, noise low,no oil leak pollution, maintenance cost low;

This model has φ1.5-φ12mm many kinds of aperture and thickness link model; the user can wilfully select according to different need to obtain the best technology and economic efficiency;

Fixed stainless steel pelletizing knife equipment, adjustment is more intuitionistic; Quick-discharge anchor ear link model, can match coordinated type pressure roller regulating mechanism and link mold hoisting equipment;

This model uses transducer control material feeding, has over loading protector, outboard discharging mechanism.

Push-brace oil pump lubricating gear, quick and saving labour, safe and reliable, can realize to refuel without stopping engine;

It's suitable to high quality animal and poultry feed, aquatic product feed and other materials pellet.

This pellet machine animal feed can process many kinds of biomass raw materials, such as corn, alfalfa, grount/peanut shell, wood chips/sawdust/shaving/logs, coffer husk, rice husk, cottone stalk, sugarcane biogases, paddy straw, sunflower straw....

Thanks to the long-term bolster and trust from clients as well as development and upgrading of technologies and services by GEMCO , There have been many poultry feed manufacturing machine set up in following countries:

poultry feed manufacturing machine by GEMCO
Continents	Countries
Europe	Germany, France, Lithuania, Republic of Ireland, Italy, Portugal, Czech, Hungary, Romania, Slovak Republic, Serbia, Montenegro, Bulgaria, Russia, Ukraine, Poland, Belarus, Croatia, Latvia, Sweden
Asia	China, Malaysia, Indonesia, Thailand, Viet Nam, India, Sri Lank
North America	the US, Canada
South America	Uruguay
Oceania	Australia

Our poultry feed manufacturing machine manufactured by GEMCO cover a wide range of pruduction yield from 0.5t/h to 12t/h, but for a smaller feed pellet making with production output of less than 0.5t/h, it can be offered as well such as a pellet making project of 300kg/h or 200kg/h.

GEMCO is capable of suppling poultry feed manufacturing machine . We hereby would like to showcase pelletizing process to lay out the general designs for both small and large scale pellet plants.
