single screw extruder pet food
- 200 Set / Sets per Month
- Shanghai Qingdao Tianjing
- T/T
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | ABC Machinery |
Model Number: | DGP70 | Type: | Feed Pellet Machine | Voltage: | 380V and 220V |
Power(W): | 18.5+0.4kw | Dimension(L*W*H): | 1600*1400*1350mm | Weight: | 420 kg |
Certification: | CE ISO | Warranty: | 12 Months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Single screw extruder pet food for dog
The single screw feed extruder use to extruded grain like soybean and corn, and can extruded the whole soybean and corn directly. The extruded product use to make floating and sinking fish food and soybean to feeding animal and pets in feed processing machines, oil pressers etc.
Product Description
This series fish food expanding machine can make crushed grain, bone powder, soybean, corn etc, into food pellets directly. Mainly suitable for all kinds of aquatic products, pet and other curing forming granule feedstuff.
1. Advantages
Our soya bean extruder machines have mainly 2 type design:
l single screw type and double screw type
l dry type without using boiler & wet type need using boiler
2.Raw material:
The raw material is: Flour,corn starch,rice bran,meat meal,bone meal,fish meal,soybean meal etc.
Fitness: about 60-80mesh which were crushed and mixed.
Moisture content: about 20%-25%.
Oil content: ≤10%
Starch content: ≥30%
Diameter of Final Pellets Can be: 0.9-12mm. Length of the pellets can be adjustable by control the cutting knife
3. Spare Parts
- With different moulds, the small fish feed pellet machine can produce different diameter food, such as 1.5mm, 2.5mm etc. So the food can meet different stage fish.
- The floating fish feed pellet machine can make poultry-fodder, pet-fodder, as well as aquaculture-fodder and fishery feed.
- The floating fish feed making machine is mainly used to process the maize flour, soybean flour or compound powder, wheat bran into high grade aquatic feed pellets for fish, catfish, shrimps, dog,. cat etc.
4. Technical parameters:
Model | Screw diameter | Capacity | Main power | Feeding power | Cutting power |
DGP50 | 50mm | 60-80kg/h | 11kw | 0.4kw | 0.4kw |
DGP60 | 60mm | 120-150kg/h | 15kw | 0.4kw | 0.4kw |
DGP70 | 70mm | 180-250kg/h | 18.5kw | 0.4kw | 0.4kw |
DGP80 | 80mm | 300-350kg/h | 22kw | 0.4kw | 1.1kw |
DGP90 | 90mm | 400-450kg/h | 30kw | 0.6kw | 1.5kw |
DGP120 | 120mm | 500-700kg/h | 55kw | 1.1kw | 2.2kw |
DGP135 | 133mm | 800-1000kg/h | 75kw | 1.1kw | 2.2kw |
DGP160 | 155mm | 1200-1500kg/h | 90kw | 1.5kw | 2.2kw |
DGP200 | 195mm | 1800-2000kg/h | 132kw | 1.5kw | 3.0kw |
5.Features:
1). The feed pellets can keep floating for over 24 hours without pollution.
2). Pellet size from diameter 0.9mm-15mm just by changing the mould.
3).High temperature and high pressure cooking process can kill the salmonellosis and bacterial infections and also makes the pellets easily to digest and absorb.
4).The cutting device can make pellets of different length.
5).The machine also can make feed for pet with different shapes and we can customized the shape for you.
6).We can provide whole fish feed pellet production line.
6. Finished pellets:
The machine can make feed with various shapes by changing the molds. Can make feed for pet like dog, cat etc with different shapes.For fish, usually is in round shapes.
FAQ
Q: What kind of raw materials should I use?
A: Soybean meal,wheat meal,corn meal,flour,bone meal,meat meal,fish meal etc.Finess in 60-80mesh.
Q: How long does the fish feed pellet float on the water surface?
A: The feed pellets made by our machine can float on the water surface for over 24 hours. While the floating time can be adjusted when the pellets are extruded.
Q: Does the machine can only make feed pellets for fish?
A: No. It’s not only can make high-grade aquatic feed pellets for fish, catfish, shrimps, crab etc., but also can make pellets for cat, dog, etc.
Q: What size of pellet can be made by your machine?
A: The size of pellet is based on the diameter of the die moulds. We can customized die moulds with diameter of 0.9-15mm.
Q: Do you supply the fish feed/pet feed production line?
A: Yes. We can supply a fish feed product line include feed hammer mill, powder mixer, fish feed pellet extruder, feed pellet dryer, fish feed pellet cooler, fish feed pellet weighing and packing machine. The capacity is from 60-2000kg/h.
Q: Is there a formula of making fish feed/pet feed pellet?
A: It totally based on the situation of your fish. We can offer free formula to our customers.
