Application
GSJ Pipeline sight glass is widely used in petroleum,chemicals, pharmaceuticals industry that can observe the the situation of fluid in the pipe directly.
Main Technical parameters
Max medium temperature:200°C
Working pressure:0.25-2.5MPa
Material: Carbon steel
Diameter:DN20-DN80
Structure and Shape dimension
PN=0.25MPa mm | ||||||
Mark model |
Diameter |
Shape dimension |
Glass plate |
Weight(kg) |
||
H |
L |
Diameter |
Thickness |
|||
GSJ-1-20-0.25 |
20 |
360 |
140 |
62 |
6 |
7.8 |
GSJ-1-25-0.25 |
25 |
360 |
170 |
90 |
7 |
10.6 |
GSJ-1-40-0.25 |
40 |
360 |
170 |
90 |
7 |
11.7 |
GSJ-1-50-0.25 |
50 |
360 |
170 |
90 |
7 |
12.4 |
GSJ-1-65-0.25 |
65 |
360 |
195 |
116 |
8 |
17.2 |
GSJ-1-70-0.25 |
70 |
360 |
230 |
114 |
9 |
21.3 |
GSJ-1-80-0.25 |
80 |
360 |
230 |
114 |
9 |
24.2 |
PN=0.6MPa mm | |||||
Mark model |
Shape dimension |
Glass plate |
Weight(kg) |
||
H |
L |
Diameter |
Thickness |
||
GSJ-1-20-0.6 |
360 |
165 |
93 |
10 |
8.7 |
GSJ-1-25-0.6 |
360 |
175 |
98 |
10 |
10 |
GSJ-1-40-0.6 |
360 |
178 |
106 |
12 |
11.4 |
GSJ-1-50-0.6 |
360 |
190 |
118 |
12 |
13.3 |
GSJ-1-65-0.6 |
360 |
195 |
123 |
15 |
18 |
GSJ-1-70-0.6 |
360 |
220 |
129 |
15 |
21.9 |
GSJ-1-80-0.6 |
360 |
235 |
155 |
15 |
25.9 |
Shenyang Beixing Meter Manufacture Co., Ltd. was founded in August of 1995. We are located at Shenyang Economic & Technological Development Area and our company covers an area of 18,000sqm. Our company is specialized in manufacturing flow & level measuring instruments, chemical glass products, chemical glass pipes and special glass apparatus. Meanwhile, we also act as an agent of mechanical & electrical products, pressure instruments, chemical reagents, chemical materials, laboratory apparatus & science equipment, contract to design the instrument and meter engineering, chemical industry pipeline & laboratory auxiliary projects, process on given materials and take mechanical manufacturing.
