Help CenterUGS-0C Side Loading and Direct-reading Type Quartz Tube Liquid Level Meter/level Gauge
Related Products
-
HG-5 Glass Plate Liquid Level Gauge/level MeterUS$ 90 - 430MOQ: 2 Units -
HG-5 Glass Plate Liquid Level Meter/ Level GaugeNegotiableMOQ: 1 Set
-
USB Glass Sheet Liquid Level Gauge With Double Color/level MeterUS$ 100 - 450MOQ: 2 Units
-
USB-L Transparent Glass Plate Level Gauge/level IndicatorUS$ 120 - 620MOQ: 2 Units
-
Input Type Hydrostatic Level Transmitter Gauge Level TransmitterUS$ 1 - 500MOQ: 1 Set
Structure
1. This level gauge is made of the quartz tube, protective cover and flange (or the liquid valves).The liquid level can be read clearly by nature light and Optical through reflection principle.
2. Two types: without the liquid valves, like UGB-1C. With the liquid valves, like UGB-2C.
The main technology parameters
1. Size(center distance): L=300~2000mm
2. The visual length and wide: L1×h=(160~1860) ×20
3. Work pressure: ≤6.3MPa
4. Medium temperature: -50~+520°C
5.Flange: diameter:DN20,DN25
Standard: PN1.0~PN6.3MPa HG20592~20635-97 raised face
According to customer's need,we can also provide other standards.
6.The meet liquid material(flange, valves)
carbon steel ; stainless steel ;special steel
7.Types
The common one: marked P
The temperature controlled one: marked W
The frost resistance one: marked F
The vessel one: marked C
8. The connection size of the temperature controlled one: G1/2” thread outside,
meantime steam pressure: ≤0.6MPa
9. The stainless ball working pressure: ≥0.3 MP
