2. Description
2.1 Model: 0762100
3. Specification
3.1 The fundamental parameters of the cell
1 ,Charge Voltage 4.2V
2, Nominal Voltage 3.7V
The average value of voltage during the discharge period (with standard charge and discharge). When shipping, the voltage without load is between 3.6V and 3.85V.
3 Nominal Capacity Typ:300mAh@ 0.2C Discharge
Min:250mAh
Nominal Capacity refer to the capacity of 0.2C discharge to 2.8V cut-off voltage, after charging with
standard method.
4 Charge Current Cell surface Temperature Charge Current
<0ºC Charge shall be prohibited
0ºC~300ºC 0.1C Max(CV:4.1V Max)
300ºC~15ºC 0.2C Max
15ºC~25ºC 0.5C Max
25ºC~45ºC 1.0C Max
5 ,Standard Charging method CC/CV 0.2CCC(constant current) charge to 4.2V, thenCV(constant voltage 4.2V) charge till charge current decline to ≤ 0.05C
6 ,Cycle Life not less than 300 Times One cycle refer to one charge period and then one discharge period.
Test condition:
Charge:0.2C to 4.2V
Discharge: 0.2C to 2.8V
The cycle life is the cycle times when the discharge capacity is about 75% of the rated capacity.
7 ,Initial
Impedance not less than 150mΩ Internal resistance measured at AC 1KHz after50% charge
8 ,Max. Discharge Current 1.0C
9 ,Discharge Cut-off Voltage 2.8V
10,Operating Temperature
Discharge: -30 ℃~ +60℃
Charge: 0℃~ +45℃
11, long term storage
temperature -5 ℃~+35℃
Relative humidity: 45~75%RH
Voltage:3.8 plus and minus 0.1V
Cells must be stored at 3.6V ~ 3.85V. Over long storage periods cells should be cycled every 90 days. The method is to do a
charge-discharge cycle withstandard method, then charge to 3.6V ~ 3.85V.
12, Cell Weight Approx:35g
13, Assemblage Dimension
Length:100mm Max
Width:62mm Max
Thickness:0.7mm Max
Measured weight of 300gf at 25℃ plus and minus 1℃.
