Applications:
- Bus & Coaches
- Truck and Trailers
- Taxi’s & Cabs
- Police & Emergency Vehicles
- Cash in Transit Vehicles
- Remote Site Surveillance
- Railways
Technical Parameters :
PARAMETER
PERFORMANCE INDEX
SYSTEM
operation language
Chinese / English
operation interface
graphical interfaces
password control
user password
VIDEO
video input
8 channels independent input: 1.0Vp-p,75Ω
video output
1 channel PAL/NTSC output, 1.0Vp-p,75Ω,
video display
1/8 screen display
video standard
PAL format 5-25 frames/sec
NTSC format 5-30 frames/sec
system resources
PAL: 200 frames; NTSC: 240 frames.
AUDIO
audio input
8 channels independent input 600Ω
audio output
single channel or 8 channel mix output 600Ω
basic output level
1.0—2.2v
distortion plus noise
≤-30dB
recording mode
sound and image synchronization
audio compression
ADPCM
DIGITAL PROCESSING
AND STORAGE
image compression
H.264 fixed code stream
image format
CIF(352*288)
video stream
8k-48kbyte / s / channel
video taking up of hard disk
28M-168Mbyte / hour / channel
resolution
playback 1ch*352*288 pixel
Video streaming standard
H.264 main profile
audio bitrate
4 kbyte / s / channel
audio taking up of hard disk
14Mbyte / hour / channel
internal storage
1 SATA hard disk,support max 2000G hard disk
image quality
eight grades to choose
ALARM
alarm input
4 channels independent input; high voltage trigger
OTHERS
power
DC8-48V 5% 8w(without hard disk)
working temperature
-20°C-+60°C
dimensions
213*230*65mm (with brachet)
weight
2.05kg(without hard disk)
clock
built-in clock, calenda
Why do you Choose us?
We are integrated factory which specialized in R&D Manufacture and Sales of of vehicle digital security and surveillance system products such as mobile digital hard disk recorders, mobile DVRs, vehicle DVRs, color CCD cameras, IR waterproof cameras, dome CCD cameras, DVR LCD displays and so on.
1. We supply the products in accordance with your requirement
2. Supply you with high quality and competitive price and promise profitable products and long time relationship
3. Humanized product design and perfect Quality Ensure System
4. Your ODM/OEM orders are welcome !
If you have any questions please contact us by email or TradeManager.
Most emails/messages are responded within 24 hours.
