4CH 1080P HDD wifi gps 3g mdvr for bus

Device parameters

Performance index

Model

TS-910-SDI

TS-910

TS-918

TS-9112

Product Name

4 Channel Mobile DVR(HDD Storage)

4 Channel Mobile DVR(HDD Storage)

8 Channel Mobile DVR(HDD Storage)

12 Channel 960H Mobile DVR(HDD Storage)

Operation System

Linux

Operation Interface

Graphical Interfaces, Chinese/English optional

File System

Proprietary Format

System Privileges

User Password

Video Input

4ch SDI Independent Input: 1.0Vp-p,75Ω.Both B&W and Color Cameras

4ch 960H Independent Input: 1.0Vp-p,75Ω.Both B&W and Color Cameras

8ch 960H Independent Input: 1.0Vp-p,75Ω.Both B&W and Color Cameras

12ch 960H Independent Input: 1.0Vp-p,75Ω.Both B&W and Color Cameras

Video Output

1 Channel PAL/NTSC Output, 1.0Vp-p,75Ω,Pin Aviation Connector

Video Display

1 Or 4 Screen Display

1 Or 4 Screen Display

1 Or 8Screen Display

1 Or 12Screen Display

Video Standard

PAL:25frames/Sec;NTSC:30frames/Sec

System Resources

PAL:100 Frames; NTSC:120 Frames

PAL:100 Frames; NTSC:120 Frames

PAL:200 Frames; NTSC:240 Frames

PAL:300 Frames; NTSC:360 Frames

Audio Input

4 Channels Independent Input 600Ω

4 Channels Independent Input 600Ω

8 Channels Independent Input 600Ω

8 Channels Independent Input 600Ω

Audio Output

1 Channel(4 Channels Can Be Convert Freely)

1 Channel(4 Channels Can Be Convert Freely)

1 Channel(8 Channels Can Be Convert Freely)

1 Channel(8 Channels Can Be Convert Freely)

Basic Output Level

1.0—2.2V

Distortion Plus Noise

≤-30dB

Recording Mode

Sound And Image Synchronization

Audio Compression

G711u

Image Compression

H.264 Fixed Code Stream

Image Format

4*1080P(1920*1080)

4*960H(960*576),4*D1(704*576)

8*960H(960*576),8*D1(704*576)

12*960H(960*576)

Video Stream

1.0M-6.0Mbit/s

192K-2.0Mbit/s

192K-2.0Mbit/s

192K-2.0Mbit/s

Video Taking Up Of Hard Disk

450M-2.6GByte/hour

85M-900MByte/hour

85M-900MByte/hour

85M-900MByte/hour

Playback Resolution

1or4*1080P

1or4*960H,1or4*D1

1or8*960H,1or8*D1

1or12*960H

Audio Bitrate

4KByte / s / channel

Audio Taking Up Of Hard Disk

14MByte / hour / channel

HDD Storage

Support Max 2TB

Image Quality

Eight Grades to Choose

Alarm in

8 Channels Independent Input. High Voltage Trigger

Alarm out

2 Channels Independent output

Move Detect

available

Host Access

Can Expand One For USB Disk Backup

Wire line Access

Can Expand One RJ45 Ethernet Port

Wifi

Can Expand One Wifi Module Inside

3G

Can Expand One WCDMA or CDMA2000 Module Inside

GPS

Can Expand GPS Module Inside

RS232

Extensible,it is convenient to connect with other vehicle equipment

RS485

Extensible,it is convenient to connect with other vehicle equipment and PTZ Camera

Intercom

Can Expand Intercom Module Inside

G-Sensor

Can Expand G-Sensor Module Inside

Canbus

Can Expand Canbus Module Inside

Power Consumption

DC8-36V 5%   ≤12W

Working Temperature

-20℃ ~ +85℃  ≤80%

Clock

Built-In Clock, Calendar

Product Size

245(L)*190(W)*71(H)mm(with Holder)

Product Weight

2.8KG(without HDD)

2.8KG(without HDD)

3.0KG(without HDD)

3.4KG(without HDD)

Package

Each In a Box, 5 sets/ Canton

Box Size

245(L)*190(W)* 71(H)mm

Carton Size

650(L)*375(W)* 255(H)mm

Carton Weight

14kgs/ 18kgs (without HDD)
