4CH 1080P mobile NVR 3G GPS wifi MDVR mobile dvr
- mobile NVR used for any vehicles
- 2.5 inch HDD, mobile dvr max 2TB, HDD& SDcard dual storage
- 4CH 1080P/960P/720P, 8CH 720P video formats with dual frame rate
- 8CH alarm in, 2CH alarm out
- support remote download and playback, video can be accurate to seconds
- Motion detection, pre-alarm record and alarm linkage
- Built in 3G/4G,WIFI,GPS,G-sensor module to be optional
- can record speed, GPS position,acceleration, emergent brake, video rearview,swerve view,alarm etc
- TES correction encrypted file management system, no video loss and protect data in 2s before power sudden off
- Support outer extend,like LED screen,ID reader,schedule monitor,passenger statistic
- DC 8 -36V wide voltage applicable for various types of vehicle
- Dual shockproof- best product structure design
- FREE SOFTWARE
TS- 910/918 -NVR (FRONT)
TS-910-NVR (BACK)
TS-918-NVR(BACK)
FREE CMS SOFTWARE
Items |
Device parameters |
Performance index |
|
Name |
Product Name |
4CH 1080P Mobile NVR |
8CH 720P Mobile NVR |
System |
Operation System |
LINUX |
|
Operation Interface |
Graphical Interfaces |
||
Operation Interface |
Graphical Interfaces, Chinese/English optional |
||
File System |
Proprietary Format |
||
System Privileges |
User Password |
||
Video |
Video Input |
4CH 1080P Digital |
8CH 1080P Digital |
4CH 960P Digital | |||
4CH 720P Digital | |||
VGA Input |
1CH Support 1920*1080 ,1280*720 ,1024*768 Resolution |
||
CVBS Input |
1 Channel PAL/NTSC Output, 1.0Vp-p,75Ω, Pin Aviation Connector |
||
Video Display |
1 Or 4 Screen Display |
1 Or 8Screen Display |
|
Video Standard |
PAL:25frames/Sec;NTSC:30frames/Sec |
||
System Resources |
1080P/960P/720P PAL:100fps,NTSC:120fps |
720P PAL:200fps,NTSC:240fps |
|
Audio |
Audio Input |
4ch independent input,600Ω |
8 independent input,600Ω |
Audio Output |
1ch CVBS output,600Ω,1.0-2.2V |
||
Distortion Plus Noise |
≤-30dB |
||
Recording Mode |
Sound And Image Synchronization |
||
Audio Compression |
G711u |
||
Digital |
Image Compression |
H.264 |
|
Image Format |
4*1080P(1920*1080) |
8*720P(1280*720) |
|
4*960P(1280*960) | |||
4*720P(1280*720) | |||
Video Taking Up Of Hard Disk |
1-8 adjust |
||
Video Stream |
1.0M-6.0Mbit/s(each ch) |
||
Video Taking Up Of Hard Disk |
450M-2.6GByte/hour |
||
Playback Resolution |
4*1080P(1920*1080) |
8*720P(1280*720) |
|
4*960P(1280*960) | |||
4*720P(1280*720) | |||
Audio Bitrate |
4KByte/s(each ch) |
||
Audio Taking Up Of Hard Disk |
14MByte/hour(each ch) |
||
HDD Storage |
1 SATA,2.5"HDD ,Max capacity 2TB; |
||
alarm interface |
Alarm in |
8 Channels Independent Input. High Voltage Trigger |
|
Alarm out |
2 Channels Independent output |
||
Move Detect |
available |
||
USB interface |
Host Access |
Can Expand One For USB Disk Backup |
|
network interface |
Wire line Access |
Can Expand One RJ45 Ethernet Port |
|
Wifi |
Can Expand One Wifi Module Inside |
||
4G/3G |
Can Expand FDD-LTE/TD-LTE/WCDMA/CDMA2000Module Inside |
||
GPS interface |
GPS |
Can Expand GPS Module Inside |
|
extend interface |
RS232 |
Extensible,it is convenient to connect with other vehicle equipment |
|
RS485 |
Extensible,it is convenient to connect with other vehicle equipment and PTZ Camera |
||
Intercom |
Can Expand Intercom Module Inside |
||
G-Sensor |
Can Expand G-Sensor Module Inside |
||
CANBUS |
Can Expand Canbus Module Inside |
||
others |
Power Consumption |
DC8-36V 5% ≤12W |
|
Working Temperature |
-20~85℃ / ≤80% |
||
Clock |
Built-In Clock, Calendar |
||
Carton Size |
245(L)*190(W)*71(H)mm |
||
NW |
2.8KG(without hdd)/pcs |
||
GW |
3.0KG(without hdd)/pcs |
||
- Powerful R&D team
- Industry experience for Several years
- Complete product range
- Excellent quality and competitive price
- Professional sales service and after-sale service
- High efficiency to meet your requirements
- Customized service(ODM and OEM are welcome)
