Help CenterPtfe Sealing Butterfly Valve
US$ 1 - 1,000
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Butterfly
Pressure:
Low Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO CHINA
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Standard or Nonstandard
Standard
Structure
Butterfly
Pressure
Low Pressure
Power
Manual
Material
Casting
Temperature of Media
Normal Temperature
Media
Other, Gas, water, oil
Port Size
DN40-DN600
Place of Origin
Shandong, China
Model Number
E50
Brand Name
EATHU
ptfe sealing butterfly valve
1. Material
| Body | cast iron+ptfe, A216 Class B+ptfe |
| Disc | Stainless steel+ptfe. CF8M+ptfe |
| Shaft | stainless steel AISI316 |
| Seat | PTFE |
| Bushing | PTFE |
2. Specifications
| Size | DN40-600 |
| Pressure | PN10/16( 150/200 PSI) |
| Actuator | handle/gear box /pneumatic /electric |
| Standard | API, ASTM, ANSI , DIN, BS, JIS ,ISO |
| Connection | wafer type, lug type |
3. Features:
Wafer, lug body style fit between FF or RF flanges.
PTFE bushing ensure the maximum shaft support and centralized alignment360 degree polished disc assures positive on-off;
Long service life, standing the test of tens thousands opening/closing operations;
EPDM with PTFE covered or Full PTFE seat for selection
Nylon or PTFE coated Disc prevent chemical corrosion from flow media
Two piece body design ensures assembly and maintenance easily
Welcome your enquiry and you will find a Reliable Supplier!
Send Inquiry to This Supplier
Business Type
Trading Company
Year Established
2004
Factory Size
Below 1,000 square meters
Total Employees
Above 1000 People
