Home > Products > Square Hole Wire Mesh > Ss wire mesh 316
Ss wire mesh 316
- 500 Square Meter / Square Meters per Month
- XINGANG
- T/T
You May Like
Product Details
| Place of Origin | Hebei, China | Material | Stainless Steel Wire | |
| Type | Weave Wire Mesh | Application | Other, petroleum, chemical industry, mine | |
| Weave Style | Plain Weave | Wire Diameter | 0.04--1.6mm | |
| Technique | Woven | Model Number | 304,304l,316,316l | |
| Brand Name | BULL |
Product Description
Specifications
Ss wire mesh 316Weaving pattern:plain or twill woven Material:304;304L;316;316L,etc
Custom orders acceptable
SS wire mesh 316
Stainless Steel Wire Mesh is classified into:plain woven and
Twill Weave ss Wire Mesh
Plain weave is the most commonly used weave. Each warp wire crosses alternately above and below each weft wire. Warp and weft wires generally have the same diameter.
Twill Weave Stainless Steel Wire Mesh is made by each weft wire passing alternately over two, and then under two successive warp wires and each warp wire passing alternately over two and under two successive weft wires. It is possible to be used to allow a heavier than standard wire diameter.
materials:304,304L,316,316L,etc
Uses:Stainless steel wire mesh and stainless steel wire cloth products are widely used in petroleum, chemical industry, environment protection, mine, airspace, paper-making,electronic, metallurgy etc.
Special size and specification are available according to customers' requirement.
Specification List of Stainless Steel Wire Mesh | |||||||
Mesh/Inch | Wire Dia (mm) | Aperture (mm) | Mesh/Inch | Wire Dia (mm) | Aperture | ||
2 | 1.60 | 11.10 | 80 | 0.13 | 0.187 | ||
3 | 1.60 | 6.87 | 100/90 | 0.10 | 0.167 | ||
4 | 1.60 | 4.75 | 100 | 0.10 | 0.154 | ||
5 | 1.00 | 4.08 | 100 | 0.11 | 0.144 | ||
6 | 0.90 | 3.33 | 120 | 0.09 | 0.122 | ||
8 | 0.90 | 2.28 | 120 | 0.08 | 0.132 | ||
8 | 0.70 | 2.47 | 150 | 0.065 | 0.104 | ||
10 | 0.50 | 2.04 | 200 | 0.05 | 0.077 | ||
12 | 0.50 | 1.62 | 200 | 0.04 | 0.084 | ||
14 | 0.50 | 0.50 | 250 | 0.04 | 0.062 | ||
16 | 0.35 | 1.24 | 250 | 0.035 | 0.067 | ||
18 | 0.28 | 1.13 | 250 | 0.03 | 0.072 | ||
20 | 0.35 | 0.92 | 300 | 0.04 | 0.045 | ||
24 | 0.35 | 0.71 | 300 | 0.03 | 0.055 | ||
28 | 0.35 | 0.56 | 325 | 0.035 | 0.043 | ||
30 | 0.28 | 0.57 | 325 | 0.028 | 0.050 | ||
40 | 0.22 | 0.42 | 400 | 0.030 | 0.034 | ||
50 | 0.18 | 0.33 | 400 | 0.023 | 0.042 | ||
60 | 0.16 | 0.26 | 508 | 0.025 | 0.025 | ||
70 | 0.14 | 0.223 |
|
|
|
| |
