Home > Construction & Decoration > Construction Equipment & Tools > Formwork > Precasting Concrete Lifting Anchor1.3T-32T
Precasting Concrete Lifting Anchor1.3T-32T
US$ 0.1 - 10
MOQ: 3000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
EATHU
Model Number:
1.3T-20T
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shandong, China
Brand Name
EATHU
Model Number
1.3T-20T
SL Anchor -The anchor is fabricated from carbon steel which has a minimum ultimate tensile strength of 75,000 psi. Both ends of the bar are hot forged; the formed head provides a spherical seating onto which the SL Lifting Eye engages, while a disc-shaped foot is provided at the lower end and is embedded in the concrete. Laboratory tests have proven that such a disc foot has more than twice the anchorage value of a hook. The maximu. |
SL Eye Anchor -This anchor is available in 1.3, 2.5, 5, 10 and 20 ton capacities. It is fabricated with an eye at the foot of the anchor and thereby allows P-60 tension bars to be attached. The SL Eye Anchor is used primarily in very thin sections, thin panels constructed with lightweight concrete or in shapes that must be handled at very low compressive strength concrete (less than 2,000 psi). The maximum safe working load in tons is embossed on the head of the anchor. |
T - Anchor -The anchor is fabricated from carbon steel which has a minimum ultimate tensile strength of 75,000 psi. Both ends of the bar are hot forged; the formed head provides a spherical seating onto which the SL Lifting Eye engages, while a disc-shaped foot is provided at the lower end and is embedded in the concrete. Laboratory tests have proven that such a disc foot has more than twice the anchorage value of a hook. The maximum safe working load is clearly visible on the head of the anchors for easy recognition of the safe lifting capacity, even when embedded in concrete. |
Eye Anchor -This anchor is available in 1.3, 2.5, 5, 10 and 20 ton capacities. It is fabricated with an eye at the foot of the anchor and thereby allows P-60 tension bars to be attached. The SL Eye Anchor is used primarily in very thin sections, thin panels constructed with lightweight concrete or in shapes that must be handled at very low compressive strength concrete (less than 2,000 psi). The MAXIMUM safe working load in tons is embossed on the head of the anchor. |
