Poultry Project Front Shutter|double-door Blower Fans

Poultry Project Front Shutter|double-door Blower Fans thumbnail-1
Poultry Project Front Shutter|double-door Blower Fans thumbnail-2
Poultry Project Front Shutter|double-door Blower Fans thumbnail-3
Poultry Project Front Shutter|double-door Blower Fans thumbnail-4
Poultry Project Front Shutter|double-door Blower Fans thumbnail-5
Poultry Project Front Shutter|double-door Blower Fans thumbnail-6
Poultry Project Front Shutter|double-door Blower Fans photo-1
Poultry Project Front Shutter|double-door Blower Fans photo-2
Poultry Project Front Shutter|double-door Blower Fans photo-3
Poultry Project Front Shutter|double-door Blower Fans photo-4
Poultry Project Front Shutter|double-door Blower Fans photo-5
Poultry Project Front Shutter|double-door Blower Fans photo-6
US$ 120 - 240 MOQ: 100 Sets
Key Specifications
Get Latest Price
Electric Current Type:
AC
Blade Material:
Stainless Steel
Mounting:
Wall Fan
Contact Supplier Request Quote Chat Now
North Husbandry Machinery (Qingzhou) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Electric Current Type AC
Blade Material Stainless Steel
Mounting Wall Fan
Place of Origin China
Brand Name NORTH HUSBANDRY
Model Number 50''
Power 1.1KW
Voltage 220/380v
Air Volume 44000m3/h
Speed 15m/s
Certification CCC, CE
After-sales Service Provided Engineers available to service machinery overseas

 Poultry farm machinery poultry house exhaust fan

exhaust fan

  50'' Super Exhaust Fan 1380x1380x450    Centrifugal shutter system exhaust fan

The Best Brands In Global Super Ventilation System For Farm



1. Exhaust Fan For Evaporative Cooling Pad System

(2. Evaporative Cooling Pad For Poultry Farm)

1. We have three models to be choose: 1380x1380x450mm and 1000x1000x450mm

Model Diameter Blades Blades rotational speed Motor  rotational speed Air flow Total pressure Noise decibels Import power Rated voltage High Widh Thick
Fan-39'' 910 mm 438 rpm 1400 rpm 21000 57 <=65 550 380 1000 1000 450
Fan-54'' 1250 mm 437 rpm 1400 rpm 44000 57 <=65 1100 380 1380 1380 450

Centrifugal Shutter System Exhaust Fan (Auto push-pull type exhaust fan)

Blade: 3 types of material for choose: stainless steel/aluminum/galvanized sheet. Adopting a punch forming technology.

Chicken House Ventilation Fan Wall Mounted Centrifugal Shutter Exhaust Fan

Centrifugal Shutter Exhaust Fan with Push-pull Device and Automatic Belt Tensioner

Frame: adopting advanced automatic manufacturing process, made of thick galvanized sheet.

Centrifugal Shutter System Exhaust Fan Push-pull Type

Shutter: made of hot galvanized sheet with thickness 1.0 and 1.2mm, to increase the quality and the stability while working.

Greenhouse Shutter Centrifugal System Exhaust Fan

Motor: both China high quality motor and Siemens motor are available. Aproved by CCC certificate, protecting level: IP55, insulation level: F class.


V-Belt: imported from Japan and Korea. Resistance to abrasion, without deformation.

Centrifugal system: adopting high-class nylon mixed with amount of fiber glass. All parts are connected by rivets. This system will be assure to open the shutter with 90 degree when the fan working.
Fan belt pulley and flange: made of high aluminum-magnesium alloy by die-casting. Light weight, low vibration. Blast-sanding treatment for attractive appearance, eliminate internal stress to improve its own rigidity and stability.



Centrifugal System Automatic Shutter Exhaust Fan
Centrifugal Shutter Type Exhaust Fan For Cowhouse&Farm



Examples of Application





Centrifugal Shutter Exhaust Fan Push-pull Type Opening Ventilation Fan
Centrifugal Shutter Exhaust Fan with Automatic Belt Tensioner

 About Company

North Husbandry(QingZhou)Machinery Co., LTD

Best Solution: Fresh Air,High Humidity and Cooling.

Evaporative Cooling Pad, Exhaust fan, Water Heating Boiler, Solar water pump, Solar insecticide lamp,Solar LED Light and so on .



SKYPE:tel-86-05363295108

Web: /

Facebook:

/husbandry.north /super.exhaust.fan.for.poultry.farm

/Evaporative.Cooling.Pad.Poultry.Farm

 Poultry farm machinery poultry house exhaust fan
