Name: DCZ Series Reflector Coating Machine
Introduction: The DCZ series perfect vacuum reflector special-purpose coating machine, is specially for automobile light, motorized headlight, street light, halogen lamp reflection cup surface aluminum-plating, or other lighting. Already approved and use by automobile manufacturer. This equipment uses the box-type structure, the high speed of pumping vacuum unit and the auxiliary pump assembly, have vacuum pumping air to be extremely quick, the production efficiency to be high, the rate of gas leakage is low, perfect vacuum stable characteristic; Disposes our company independent research and development the new evaporation organization, the coating level is even, the adhesiveness is good, the product quality is stable, is reliable. Is plates material quality reflector's and so on system plastic, metal, BMC, glass ideal equipment.
Main Features:
1. The stainless steel vacuum chamber and the exhaust pipeline, is advantageous in enhances the vacuum speed of pumping;
2. The big speed of pumping vacuum system, the auxiliary pump assembly, the vacuum is stable, the film quality is good, the production efficiency is high;
3. Independent research and development new vacuum exhaustion structure, when avoids pulls out thickly the coating indoor impurity sucking in effectively proliferates the pump;
4. The independent research and development's new resistance evaporation structure, the coating uniformity, the binding force have compared to the traditional evaporation structure enhance largely.
Main Configuration:
1. Vacuum chamber: Vertical and double door, the box-type structure, the stainless steel material quality;
2. Vacuum system: Big speed of pumping system, stainless steel pipeline and valve;
3. Coating system: In each gate matches a set of new resistance evaporation organization;
4. Control system: Touch screen +PLC, the completely automatic or the hand control may transform;
5. Safety device: Establishment water, electricity, gas unusual acousto-optics alarm device;
6. Auxiliary pumping system: A fast circulation low temperature water vapor trap set.
Technical Parameter:
1. Chamber size (mm): Deep 750, wide 750, high 1150;
2. Machine size (mm): Deep 4000, wide 3000, high 2100;
3. Ultimate vacuum (new machine, idling, dry): ≤6×10-4Pa;
4. Secondary recovery time (new machine, idling, dry): From 1×105Pa to 5×10-2Pa≤3min
5. Total output: 90 KW;
6. Total weight: 5T.
