48V 2000w Home Use Sine Wave Power Inverter

Anhui Jing Neng Green Energy Co., Ltd.
48V 2000w Home Use Sine Wave Power Inverter thumbnail-1
48V 2000w Home Use Sine Wave Power Inverter photo-1
US$ 39 - 40 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
JN
Model Number:
JN-PW2000-48
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Anhui, China
Brand Name JN
Model Number JN-PW2000-48
Output Power 1 - 200KW
Output Type Single
Size 425*200*335
Weight 17
Input Voltage 36V
Output Voltage 110V/220V/240V
Type DC/AC Inverters
Output Frequency 50HZ/60HZ
Output Current 50A

Specifications

48V 2000w home use Sine Wave Power Inverter
Model JN-PW2000-48
Rated 48v

  48V 2000w  home use Sine Wave Power Inverter

Sine wave inverter series
Features:
Advanced performance by CPU control
Auto voltage regulation(AVR),wide input voltage 145V~275V,accurate output,AVR function,adapt all kinds lf bad electric environments
Intelligent battery charging, the charging current can be adjusted according to the equipped battery, it is fast and reliable and can increase the service life of the battery
 Intelligence display of output voltage,frequency,battery capacity,fault,over load,load
 User can use the program of RS232 or USB communication′s software to setting timing auto shut down
 Generator compatibly and external battery connection achievable
Adapt all kinds lf bad electric environments
 It can be automatically started up with mains supply, and has a wider range of applications
 Advanced automatic constant charging circuit,prolongs battery life
  It has perfect battery under-voltage, overload, over-discharge, short-circuit protections
Technical specification
Model XD-NB
Rated power1400W2100W2800W3500W
Battery24VDC/36VDC/48VDC48VDC/96VDC
Size(W×D×H)mm405×180×320425×200×335
Shipping size(W×D×H)mm460×240×380490×290×410
Net weight(kg)17202831
Gross weight (kg)18212932
Universal parameter
InputVoltage145V~275V
Frequency45Hz~65Hz
OutputVoltage220V±2%(Battery mode)
Frequency50Hz±0.5%
Output wave fromSine wave
Output wavefrom distortion≤±0.3%
Charging5A-15A(Adjustable)
DisplayLED,LCD(Optional)
Transfer time<4ms
SurroundingNoise≤50dB
Temperature0°C~40°C
Humidity10%~90%(no condensate)
Efficiency≥80%
ProtectionOverloadOverload110%,30seconds automatic closed-down;Overload120%,2seconds automatic closed-down;city electric mode overload not closed-down,the buzzer sends out alarm sound
Short-circuit Output short-circuit, a buzzer ringing, 20 seconds after the automatic closed-down
BatteryBattery high-voltage and low-voltage protections
Reverse polarityBattery reverse polqrity protections
Alarm soundAWhen the city electricity when in normal work,the maching without alarm,when the utility power failure,the machine is in the working state of the battery,a buzzer 30 seconds each tweet 4
BBattery low voltage alarm buzzer two times per second,a call.Battery mode,the maching fails,the buzzeris urgeng
COverload buzzer,tweet once per second
RemarkSpecification only for reference.Subject to change prior notice





 48V 2000w home use Sine Wave Power Inverter







                                                                 An Hui Jing Neng Green Energy Co.,Ltd
              www .
 Tel : 86-13788918712         Fax : 86-551-8564587
