Home > Products > Truck-mounted platform > New product hydaulic car-mounted man lift
New product hydaulic car-mounted man lift
- 300 Set / Sets per Month
- Shanghai/Shenzhen
- T/T
Product Details
| Place of Origin: | Hunan, China | Brand Name: | Runshare | Model Number: | JX5080JGKH-24 |
Product Description
truck-mounted aerial work platform (24meter)
Maximum Lift Capacity:200KG
| Model | JX5060JGKH-24 |
| Working Height Maximum | 23.68m |
| Platform Height Maximum | 21.98m |
| Working radius maximum | 11m |
| Working radius (height maximum) | 2.0m |
| Platform height(radius maximum) | 10.7m |
| Lift capacity | 200kg |
| Crossing height maximum | 10m |
| Outriggers span (longitudinal*transverse) | 4.3*3.4m |
| Turntable swing | 360°continuous |
| Platform rotation(optional ) | ±90° |
| Platform leveling | Differential volume |
| Control mode | Multi-way Manually-control value |
| Platform measurement | 1.4*0.7m |
| Tower boom lift time | 40s |
| Boom lift time | 40s |
| Extension speed | 50s |
| Swing speed | 0~1/3rpm |
| Outrigger speed (retracted/extended) | ≤80/80s |
| Length | 8200mm |
| Width | 2200mm |
| Height (stowed/transport in container) | 3100mm |
| Front overhang | 1015mm |
| Rear overhang | 1455mm |
| extension | 1450mm |
| Maximum total mass | 7500kg |
| The Front Axle load | 3400kg |
| The Rear Axle Load | 4100kg |
| Number of person | 3 |
| Chassis type /the maximum speed / ramp breakover/ transverse angle/ ground clearance minimum/ approach angle/ departure angle/engine type/ maximum power | Matching |
Core technology
Production capacity
Certificate
Trade show
We join BAUMA MUNICH,BAUMA SHANGHAI,BIG5 DUBAI,M&T BRAZIL,APEX NERTLND,INTERMAT PARIS,CONEXPO LAS VEGAS,BUILD TECH SIGAPORE,CONSTECH BANGKOK and so on.
Company Information
About Us
Runshare is the biggest manufacturer of aerial work platform in China. We can supply the telescopic boom, articulated boom and scissor platform from 5m to 44m.
Contact Us
ADD:Runshare industry park,Lingang new industrial Zone,Changsha, Hunan, China
Tel: 0086-731-84939476
Email:sales5@runshare.
Why Choose Us
1.Runshare is real manufacturer engaged in research, development, manufacturing, sale and service of aerial work equipment from 4m to 44m.
2. We could help customer choose the right model specially..
3. Main elements are used world famous brand.
4. Provide timely delivery,Sales engineers are ready to solve all problem.
5. Provide spare parts, worksite installation guidance and training operation.
9.Our Services
1. Pres-ale service: Free comprehensive and detailed technology consultancy in construction sites, referential programs for construction equipment and the most suitable product program.
2. In sale service: We provide free guidance of installation and debugging and free training of operation, care and maintenance.
3. After-sale service: One-year warranty service of whole machine and lifetime maintenance; regularly markets visits and free guidance of whole machine’s maintenance and reparations.
4. Quick responses: we have a complete service network, hotline(86-731-84939476) services for 24hours and assist you to solve the problem in a short time.
5. Parts supply: we have a complete parts supply network and can guarantee sufficient parts reserves and timely supply.
10.FAQ
1. Delievery Time?(From 1 week to 1 month after we receive the order)
2. payments?(T/T and L/C, other kinds, pls contact with us)
3. MOQ?(1 set)4. Trade term? ( FOB/CIF to your nearest seaport)
4. Power source?(Battery or Diesel engine)
5. Drive motion?(2 wheel driving or 4 wheel driving)
6. Application field?(construction, shipyard, industrial, airport, municipal garden
or others)
