1.8ton Crawler Excavator With Japan Yanmar Engine

Specifications

1.PRODUCTION INFO.

1.8ton MINI crawler excavator CT18-7B with CE certification.hydraulic.hammar,tilt bucket,quick hitch.small digs machine.

Operating weight: 1760kgs
Bucket capacity: 0.05cbm
Engine:Japan Yanmar engine 3NTV82A diesel--21hp
Originally imported US Parker double-connecting gear pump
Originally imported Italian Comer walking motor and reduce
Originally imported US Eaton swing motor
Originally imported Italian hydraulic main valve
Originally imported Italian pilot control lever
Originally imported Italian Oil-sucking vave.
Rubber tracks,Luxury cabin or canopy

cabin with heater & fan

AXIAL PISTON PUMP and GEAR PUMP
CONSTANT POWER VARIABLE DISPACEMENT WITH GEAR PUMP OVERRIDE CONTROL
FLOW/PRESSURE 45.8*2+37 l/MIN @ 2.200 RPM / 21MPA
GEAR PUMP
FLOW/PRESSURE 22*2 L/min @ 2.200 rpm / 16 mpa
over load pressure
BUCKET 20 MPA

Compact, flexible and easy to operate
Suitable to operate in small space and difficult working environment
With excellent efficiency and performance
Flexibility is the core of operation. Because of using of best hydraulic pressure
systems, radius, dipper handle and bucket they work together in a flexible,
fast and effective manner.
Comfortable and stable operating environment;
2--door cabin, low noise, low-vibration seat, flexible operation handle and scientific
configuration of various buttons all reflect The best driving environment
Fully-open engine hood is easy for maintenance
Features:
For routine check, simply opening the engine cover, you can check the engine,
clean air cleaning filter and replenish cooling water;
Smart operation system
New maximizes working efficiency and reduces fuel consumption;
LCD monitor makes operation more visual.

2.SPECIFICATION

3.OPTIONS.

Besides standard bucket with width 450mm,we also supply 300mm width,1000mm width bucket,tilting bucket,hammar

 CAPACITY OF ABOVE BUCKET IS 0.1CBM

CONTACT US FOR MORE PLEASE~~
