Foshan Headly Fully automatic 1kg 2kg 3kg 5kg rice packaging machine

Name: Foshan Headly Fully automatic 1kg 2kg 3kg 5kg rice packaging machine
Brand: Headly
Price: USD $1,000 - 10,000 / Set

FOB Price

USD $1,000 - $10,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Guangzhou
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Function:	Sealing, Wrapping	Application:	Beverage, Chemical, Food, Medical
Packaging Type:	Bags, Film, Pouch, Stand-up Pouch	Packaging Material:	Plastic, Wood	Automatic Grade:	Automatic
Driven Type:	Electric	Voltage:	220V	Power:	3.0KW
Place of Origin:	Guangdong, China	Brand Name:	Headly	Model Number:	HDL-420D/520D/680D
Dimension(LWH):	(L)960x(W)930x(H)1600mm	Certification:	CE	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

Foshan Headly Fully automatic 1kg 2kg 3kg 5kg rice packaging machine

Product Description

PRODUCT INFORMATION

Model No	420D	520D	680D	900D	1050D
Product Application	Granule	Granule	Granule	Granule	Granule
Range Of Application	High Accuracy And Easy Fragile Material:Chips,Candy,Pet Food,Chocolate,Apple Slices,Dumpling,Medicine
Volume Range	Max.1000Ml	Max.2000Ml	150-4000 Ml	1-25 L	1.5-45L
Packing Size (Mm)	Length:30-800 Width:80-200	Length:80-350 Width:100-250	Length:100-450 Width:100-300	Length:100-600 Width:260-430	Length:100-800 Width:290-505
Machine Motion	Intermittent
Machine Control Through	Plc
Machine Speed	10-65 Bag/Min	5-60 Bag/Min	10-40 Bag/Min	5-20 Bag/Min	5-20 Bag/Min
Film Width	Max.420	Max.520	Max.680	Max.900	Max.1050
Packing Film	Any Heat Sealable Laminated Roll
Power	220V50Hz.3Kw	220V50Hz.3Kw	220V50/60Hz.3.6Kw	220V50/60Hz.4.5Kw	220V50/60Hz.5Kw
Machine Size (Mm)	L:1217 W:1015 H:1343	L:1488 W:1080 H:1490	L:1716 W:1260 H:18200	L:2305 W:1685 H:2725	L:2900 W:2050 H:3300
Machine Weight	650 Kg	750 Kg	900 Kg	1200 Kg	1500 Kg
Feeding System	Weigh Filler
Packing Film Pulling	Through Electromagnetic Clutch And Brake
Contact Parts	Food Grade Stainless Ss 304
Sealing Type	Center Sealing; Pillow Type
Main Motor	Main Motor For Panasonic
Temperature Controller	Pid Based
Machine Features	Individual Temperature Control, High Speed Counter, Voltage Vector Control
Language	English+Arabic+Any
Additional	Toolbox+Operation Instruction
Optional Features	Punching Cutting Device, Pneumatic Coding Device, Nitrogen Flushing Device

PRODUCT DISPLAY

Customized Service

Kindly Reminder:

Please let us know the follow packing details when you offer, so that we can check if this model is suitable for your case. Thank you in advance.

Product details
Bag width, bag length (similar picture)
Bag shape
Packing film material
Machine frame

The finished product is shown as the figure above. A part of the components are customizable and you can use them to assemble the machine you need.

Optional Parts:

Measuring Cup Device

Combination Weigher

Screw Metering Machine

Plunger Pump Or Gear Pump Metering System

Hdl Series Main Machine

Z Type Bucket Elevator

Vibration Feeder

Supporting Platform

Product Conveyor

Screw Infeed Conveyor

Material Elevator

Nitrogen-Making Machine

Check Weigher

Metal Detector

Nitrogen-Making Machine

And So On

Product Advantage

PRODUCT ADVANTAGE

1.Efficient: to finish the production, sealing, packaging and date printing in one time.

2.Intelligent: automatic stop function, unsticky and not wasting the films.

3.Convenient: labor-saving, low loss, easy to operate and maintain.

CORE ADVANTAGE

Large Vertical Automatic Packaging Machine- Multiple Choices

Auger filler	Volumetric cup	Weighter
SPARE PARTS

Spare parts	Brand
Temperature-controlled meter	Temperature-controlled meter from China for SHANGHAI YATAI
Horizontal cylinder	Horizontal cylinder from Taiwan for AIRTAC
Cutting thin cylinder	Cutting thin cylinder from Taiwan for AIRTAC
Push membrane cylinders	Push membrane cylinders from Taiwan for AIRTAC
FR&L	FR&L from Taiwan for AIRTAC
Reducing valve and pressure gage	Reducing valve and pressure gage from Taiwan For AIRTAC
Solenoid valve and valve plate	Solenoid valve and valve plate from Taiwan for MINDMAN
Filling solenoid	Filling solenoid from Taiwan for MINDMAN
Intermediate relay	Intermediate relay from Japan for IZUMI
Switching power supply	Switching power supply from Taiwan for FOTEK
