amsky kodark plates offset ctp machines
Competitive Advantage:
Mature and reliable 32-64 channels; Discrete 830nm laser diode technology
Extremely clear and sharp screen dots can be exposed; Resistance rate is high and it’s operated in light room; Service life extends as long as tens of thousands of hours; Replacement is economic and convenient.
Dynamic and Automatic Focusing
Track in real time the variation of surface fluctuation and adjust the lens forwards or backwards to assure the distance between exposure dots and lens is unchangeable. Each laser spot is exposed at the best focal length to assure all the screen dots are accordant, clear and sharp.
Special Screen Dots Control Technology
Screen dots gain problems caused by size of laser spots are accurately compensated for so that 1%~ 99% grayscale gradients is perfectly presented.
Exposure Design with External Drum Style
The printing plates are clamped and bent in the style closest to the press, high-quality and exactly accordant dots are exposed and printing forms are output at high speed up to 29 pages of 1030x800mm per hour.
Convenient Operation
High-speed USB2.0 interface makes ALPHA CTP have Plug and Play function like a desktop printer. The aided output management software (Tiff download) can realize seamless link with any mature workflow.
Technical Specifications
Ausetter 400T Specifications | ||||
Model |
T424 |
T432 |
T448 |
T464 |
Exposing Method |
External Drum |
|||
Imaging System |
24-channel |
32-channel |
48-channel |
64-channel |
Discrete 830nm laser diode | ||||
|
Throughput
|
12 plates per hour |
16 plates per hour |
22 plates per hour |
28 plates per hour |
800mmx660mm 2,400dpi | ||||
Plate Size |
Max. 800mmX660mm, min.400X300mm |
|||
Exposing Size |
Max.800mmX646mm, min. 400mmX284mm |
|||
Media Type |
830nm thermal plate |
|||
Plate Thickness |
0.15mm to 0.3mm |
|||
Resolutions |
2,400dpi |
|||
Repeatability |
Continuous exposing for four times or above on the same plate with a temperature of 23°C and humidity of 60%) |
|||
Interface |
USB2.0 |
|||
Plate Loading |
semi automatic |
|||
Weight |
800KG |
|||
Size (W xDx H) |
1,900mmx1,200mmx1,000mm ( WxDxH ) |
|||
Power Supply |
single-phase: 220AC, +6%, -10%, Power Consumption: 4KW |
|||
Environment |
Recommended: 21-25°C, Max. 18-26°C, humidity: 40-70% |
|||
Professional service team:
Product Video:
Any questions feel free to contact with us!
