Specifications
offset printing CTP plate making machine1.Good price, easy operation
2.High-Resolutin Imaging System
3.External drum
offset printing CTP plate making machine
Feature: Independent vacuum structure, effectively absorb various plates.
DOIE Thermal-CTP uses the most advanced and stable V model guide rail fixed position technology, using automatic loading way and 830nm laser diode, made the high energy field value of thermal material development, high development quality, after baking , the thermal plate could prints about million times.
DOIE Thermal-CTP is full digital controlled technology, not only is a mature commercial products and the source of profits, but also to the prepress printing integration technology development which have the immeasurable influence and realistic significance.
Applications:
CTP platemaking machines generally divided into inside drum, the drum type, plate type, curve type four major categories. In the four types at present, the most use is the internal drum and the drum; The performance with most high-grade CTP platemaking machines are the drum type.
Digital workflow is integrated control the whole printing production process software system.
Recently, mainstream digital working flows in the market are all applied to DOIE-CTP series
Specifications:
Model |
X-0642T |
Light Channels |
64 |
Output Speed(P/h) |
29 |
P size:1030mm×800mm | |
Light Source |
830 nm Laser Diode |
Output Resolution (dpi) |
2400 |
Dot Reproduction |
1%~99% |
Register Accuracy (mm) |
<0.01 |
Plate Size (mm) |
Max. 1160×940;Min. 450×320 |
Suitable Plates |
Various thermal ctp plates |
Plate Thickness (mm) |
0.15~0.30 |
Plate Loading and Unloading |
Loading:Automation(Standard Set) Unloading:Automation Vacuum Fixation |
Plate Position Accuracy (mm) |
0.2 |
Plate Balance |
Automatic Balance |
Data Interface |
USB,1000Mbit/s |
Ambient |
Temperature 25°C±3°C Humidity 20~80%(Non-condensing) |
Machine Dimension (mm) |
L2200×W1100×H1050 |
Net Weight (kg) |
1500 |
Power Supply |
≤6KW/220V±5%,50/60Hz |
Competitive Advantage:
1. Precise guiderail chassis. Manual entire scrape.
- The chassis is HT300 inblock cast, guiderail and chassis became in one, the high mechanical strength, the high heat stability, less possibility of deformation.
- The guiderail precision could achieve 1-3μm/m,effectively ensure printing precision.
- Scraping guiderail is made by cast-iron, the surface has one thin oil slick, play an lubricant, protective role;
- Using import soft guide pairs and precise grinder guiderail technology, make optical platform move has little wear; the moving of platform has better smooth, precision.
2. Independent vacuum structure, effectively absorb various plates.
- By using the three-cavity technology, the drum could effectively absorb various plates, avoid the plate.
- According to different size of plate, adjust absorptive power, could achieve best printing effect.
- Using negative pressure checking before printing, avoid the plate flying.
- Using negative pressure checking in printing, avoid the plate flying.
- Using negative pressure and prevent air leakage technology.
3. High precision side-guide technology, improve printing repeatability precision.
- Fusing advanced plate-edge checking technology and side-guide technology, improving the printing repeatability precision.
- High precision side-guide technology, making the equipment running more stable.
- According to the requirement, increase dynamic balance data automatically, make the production conveniently.
4. Continue feeding plate system, achieve automatic loading plate.
- Using advanced belt conveying plate system.
- Using mechanical head clip automatic positioner.
- Using mechanical tail clip automatic positioner.
- Using automatic negative pressure absorption technology
Certificate
Work Flow
Professional Service Team
Product Video
Any question please feel free to contact with us!
