Specifications
Industrial Mixer/galena concentrating plant1.Mix ore with chemical agent
2.For froth flotation
3.Automatic
4.Install
Industrial Mixer /galena concentrating plant
Industrial Mixers and Blenders are used to mix or blend a wide range of materials used in different industries including the food, chemical, pharmaceutical, plastic and mineral industries.
They are mainly used to mix different materials using different types of blades to make a good quality homogeneous mixture. Included are dry blending devices, paste mixing designs for high viscosity
products and high shear models for emulsification, particle size reduction and homogenization.
Industrial mixers range from laboratory to production line scale.
They can operate at different temperatures and pressures for mixing different solutions and can also have internal or external heating systems added to them.
Options also exist where spray nozzles, CIP, PLC and pneumatic or electric systems can be used. Systems can come equipped with hydraulic or electronic soft start mechanisms so that they start and stop smoothly.
In addition to performing typical batch mixing operations, some mixing can be done continuously. Using a machine like the Continuous Processor, one or more dry ingredients and one
or more liquid ingredients can be accurately and consistently metered into the machine and see a continuous, homogeneous mixture come out the discharge of the machine.
Many industries have converted to continuous mixing for many reasons. Some of those are ease of cleaning, lower energy consumption, smaller footprint, versatility, control, and many others.
Continuous mixers, such as the twin-screw Continuous Processor, also have the ability to handle very high viscosities.
Parameter:
| Model | Chute Inner Dimension | Efficiency Volume(m3) | Mixer | Motor | Weight(kg) | |||
| Diameter(mm) | Depth(mm) | Diameter(mm) | Rotation Speed(r/min) | Model | Power(kw) | |||
| XB-750 | 750 | 750 | 0.26 | 240 | 530 | Y90S-4 | 1.1 | 228 |
| XB-1000 | 1000 | 1000 | 0.58 | 240 | 530 | Y90L-4 | 1.5 | 436 |
| XB-1200 | 1200 | 1200 | 1.14 | 400 | 320 | Y100L2-4 | 3 | 765 |
| XB-1500 | 1500 | 1500 | 2.2 | 400 | 320 | Y100L2-4 | 3 | 1083 |
| XB-2000 | 2000 | 2000 | 5.46 | 550 | 230 | Y132M2-6 | 5.5 | 2100 |
| XB-2500 | 2500 | 2500 | 11.2 | 650 | 200 | Y160L-6 | 11 | 3438 |
| XB-3000 | 3000 | 3000 | 19.1 | 700 | 210 | Y225S-8 | 18.5 | 4613 |
| XB-3500 | 3500 | 3500 | 30 | 850 | 230 | Y225M-8 | 22 | 7110 |
Details:
Factory:
