Rotary Kiln Calcination Plant / Bauxite Calcination Plant / Calcined Bauxite Rotary Kiln
US$ 1 - 99,999
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
sievo
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Rotary Kiln / Furnace Rotating Kiln / Rotary Drying MachineUS$ 100 - 100,000MOQ: 1 Set -
Rotary Dryer Drawing / Fertilizer Coating Machine / Clay DrierUS$ 100 - 100,000MOQ: 1 Set
-
2013 Cement Rotary Kiln Suppliers / Cement Rotary Kiln Professional ManufacturersUS$ 100 - 100,000MOQ: 1 Set
-
Rotary Dryer Price / Sand Rotary Dryer / Coal DrierUS$ 100 - 100,000MOQ: 1 Set
-
Kiln in Cement Industry / Rotary Kiln Cement / Cement Kiln FuelUS$ 100 - 100,000MOQ: 1 Set
Condition
New
Place of Origin
Shanghai, China
Brand Name
sievo
Model Number
dia.2.5*44m
Voltage
380V
Power(W)
40000
Dimension(L*W*H)
44m*2.5m*2.5m
Weight
177(excludes refractory bricks and kiln hood
Certification
ISO9001:2000
Warranty
one year warranty
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Bauxite Calcination Plant1.environmental protection
2.recycling
3. high efficiency
4.low heat consumption
Rotary Kiln Calcination Plant |
We provide the a state of art Rotary Calcination Plant, which adds value to the industrial minerals like Kaolin, Bauxite, Bentotine, Ball Clay etc. Our design is approved and recknoginzed by Shangahi Sievo Heavy Equipment Co.,Ltd. |
We are well known manufacturer of the wide range of Calcination Rotary Kiln with two cyclone separators and allied accessories. Made by using high grade raw materials, these are produced in our latest technology laden production unit. Our machines are well capable of reducing the consumption of oil to 50% and black ash. With all international specifications in place, these machines are of highest quality.
|
|
We stand as one of the leading manufacturers of Bauxite Calcination Plant, manufactured from superior quality of raw materials. Some of the attributes of these machines are durability, robust, efficiency and cost effectiveness. Available in Capacity from 2 mt/hr up to 50 mt/hr, these are fired with Petcoke, Oil, Gas and Coal Gas. We also provide dual fire option as well.
|
|
We offer uniquely designed china clay calcination plant, which operates on Natural Gas or Producer Gas or Furnace Oil fuels. The plant is capable is complete in all respects i.e. from Filter Press cake with moisture more 20% to the final micronized calcined product. The product is at par in quality with international players.
|
|
Our range of Rotary Dryer & Cooler Plants is well known for its international quality, durability and reliability used for drying and cooling of free flowing materials. Fabricated from superior quality raw materials, these dryers and coolers are extensively used in array of industries. Made in our latest technology equipped production unit by team of dedicated technicians, these are known for its specific design, durability and quality performance. A rotary dryer and cooler operates in the following manner:
|
|
We are well known manufacturer of the wide range of Dolomite Calcination Plant with two cyclone separators and allied accessories. Made by using high grade raw materials, these are produced in our latest technology laden production unit. Our machines are well capable of reducing the consumption of oil to 50% and black ash. With all international specifications in place, these machines are of highest quality.
|
|
We offer uniquely designed china clay calcination plant, which operates on Natural Gas or Producer Gas or Furnace Oil fuels. The plant is capable is complete in all respects i.e. from Filter Press cake with moisture more 20% to the final micronized calcined product. The product is at par in quality with international players.
|
|
We stand as one of the leading manufacturers of Calcined Bauxite Rotary Kiln, manufactured from superior quality of raw materials. Some of the attributes of these machines are durability, robust, efficiency and cost effectiveness. Available in Capacity from 2 mt/hr up to 50 mt/hr, these are fired with Petcoke, Oil, Gas and Coal Gas. We also provide dual fire option as well.
|
calcination rotary kiln Main Specs. and Parameters
Spec.(m) |
Φ2.8/2.5×44 |
Φ3.3×50 |
Φ3.5×54 |
||
Capacity(t/d) |
300 |
1200 |
1500-1800 |
||
Supporters No. |
3 |
3 |
3 |
||
Type of thrust roller |
Mechanical |
Mechanical |
Mechanical |
||
Rotating speed of kiln |
Main driving(r/min) |
0.445-2.22 |
0.36-3.57 |
0.39-3.9 |
|
Auxiliary driving(r/min) |
4.75 |
5.61 |
7.66 |
||
|
Main driving
|
Electrical motor
|
Model |
ZSN4-225-21 |
ZSN4-280-091B |
ZSN4-315-092 |
Rated power(kw) |
55 |
160 |
220 |
||
Speed regulation range(r/min) |
~1000 |
1500 |
1000 |
||
Rated power(v) |
440 |
440 |
440 |
||
Reducer |
Model |
ZS145-1-I |
ZSY450-40 |
NZS995-28VIBL |
|
Rated power(kw) |
49-63 |
40 |
28 |
||
Auxiliary driving |
Electrical motor
|
Type |
Y122M-4 |
Y160M-4 |
Y200L1-6 |
Rated Power(kw) |
4 |
11 |
18.5 |
||
Rated speed(r/min) |
1440 |
1460 |
970 |
||
Rated voltage(v) |
380 |
380 |
380 |
||
Reducer |
Model |
ZL35-16 |
ZSY355-31.5 |
ZSY355 |
|
Total ratio |
40.44 |
31.5 |
45 |
||
Total weight (excluding refractory brick) |
177 |
281 |
341 |
||
Weight of discharging kiln hood |
20 |
27 |
28 |
||
