Specifications
ceramic sand rotary kiln :features environmental protection,
recycling,high efficiency,
low heat consumption
Ceramic sand Rotary Kiln/ Rotary Kiln
cement rotary kiln/cement equipment/limestone rotary kiln
Cement Rotary Kiln Introduction
Cement rotary kiln is main equipment in dry and wet process line of the cement clinker. And it is widely used in metallurgy, chemical industry, building construction, refractory material, environmental protection industry, etc. This series kiln is manufactured on the base of technological innovation, which adopts the latest international techniques. And it features easy and reliable operation. Compared with traditional device with the same specifications, it increases the operation rate by 10%, the output by 5%-10%, and saves the consumption by15%. Moreover, it has advantages of steady structure, stable operation and good quality of the end products.
Working principle
This equipment consist of barrel, thrust roller supportive device, driving device, active burner hood, sealing device of kiln tail, and burning device, etc. The body of rotary kiln is placed according fixed slope and supported by supporting device. The blocking wheel device controls the kiln bouncing up and down. Except setting the main transmission,it also set supplementary transmission device to make the kiln rotating. It prevents the kiln body bending deformation when the main power supply interrupts suddenly. Besides, the kiln head adopts shell-type sealing system, and the kiln tail equips with the axial contact-type sealing device, have guaranteed sealed dependability.
Features and Benefits
Simple structure, stable operation;
Large output, high quality;
Convenient and reliable in controlling the production process.
Few wearing parts, high operation rate;
Pro-environment, recycle the waste resource;
Cement Rotary Kiln/Clinker Rotary Kiln/Limestone Rotary Kiln Main Specs. and Parameters
Spec.(m) |
Φ2.8/2.5×44 |
Φ3×48 |
Φ3.2×50 |
Φ3.3×50 |
Φ3.5×54 |
||
Capacity(t/d) |
300 |
600-700 |
1000 |
1200 |
1500-1800 |
||
Supporters No. |
3 |
3 |
3 |
3 |
3 |
||
Type of thrust roller |
Mechanical |
Mechanical |
Mechanical |
Mechanical |
Mechanical |
||
Rotating speed of kiln |
Main driving(r/min) |
0.445-2.22 |
0.676-3.38 |
0.36-3.57 |
0.36-3.57 |
0.39-3.9 |
|
Auxiliary driving(r/min) |
4.75 |
9.36 |
6.5 |
5.61 |
7.66 |
||
|
Main driving
|
Electrical motor
|
Model |
ZSN4-225-21 |
Z2-101 |
ZSN4-280-091B |
ZSN4-280-091B |
ZSN4-315-092 |
Rated power(kw) |
55 |
100 |
160 |
160 |
220 |
||
Speed regulation range(r/min) |
~1000 |
~1500 |
1500 |
1500 |
1000 |
||
Rated power(v) |
440 |
220 |
440 |
440 |
440 |
||
Reducer |
Model |
ZS145-1-I |
ZS145-1-1 |
ZSY-450-40-V |
ZSY450-40 |
NZS995-28VIBL |
|
Rated power(kw) |
49-63 |
50 |
40 |
40 |
28 |
||
Auxiliary driving |
Electrical motor
|
Type |
Y122M-4 |
Y160M-6 |
Y160M-4B |
Y160M-4 |
Y200L1-6 |
Rated Power(kw) |
4 |
7.5 |
15 |
11 |
18.5 |
||
Rated speed(r/min) |
1440 |
970 |
1460 |
1460 |
970 |
||
Rated voltage(v) |
380 |
380 |
380 |
380 |
380 |
||
Reducer |
Model |
ZL35-16 |
ZL35-7-1 |
ZSY160-31.5-2 |
ZSY355-31.5 |
ZSY355 |
|
Total ratio |
40.44 |
14 |
31.5 |
31.5 |
45 |
||
Total weight (excluding refractory brick) |
177 |
207 |
256.5 |
281 |
341 |
||
Weight of discharging kiln hood | |||||||
