New generation hot-selling tablet counting and filling machine
- 99 Set / Sets per Month
- Shanghai or any port
- T/T L/C D/P D/A Credit Card
- Cheapest Automatic Bottle Blowing Machine Prices/factory price automatic bottle shrink wrapping machine
- PET bottle making machine/nice plastic bottle making machine price/high quality plastic bottle blowing machine
- Top quality china automatic machines to make plastic bottles/bottle blowing machinery/Pet Bottles Blowing Machine 750ml
- Chinese PET water bottle blowing machine/equipment / automatic bottle Blowing machinery
- Low price Beverage drinking PET bottle blowing machinery/fully automatic pet bottle blowing machine
- high quality bottle blowing machine/automatic shrink wrapping machine/water bottle blowing machine
Product Details
Condition: | New | Application: | Beverage, Chemical, Commodity, Food, Other, Medical, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical | Packaging Type: | Barrel, Bottles, Cans |
Packaging Material: | Glass, Metal, Plastic | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 220/380v | Power: | 800w | Place of Origin: | Shanghai, China |
Brand Name: | SQUARESTAR | Model Number: | CCD-16 | Dimension(L*W*H): | 1800*1540*1600mm |
Weight: | 500kg | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Model | tablet counting and filling machine |
Counting & Filling Speed | 2000-4000 pieces/minutes based on 20-999 pieces/bottle |
Channel | 16 |
Diameter of bottle | 35-100mm |
Height of bottle | 40-240mm |
Dimensions | 1800mm×1540mm×1600 mm ( L × W × H) |
Weight | 650kg |
Electrical Requirements | 800W, 220v, 50-60HZ(Optional) |
Working direction | Left → Right (or Right → Left) |
l CCD technology with high speed digital camera
l Highly anti-dusty design
l Suitable for various capsule with different transparency
l Speeds up to 60 cpm based on 100-count bottles with vibration system
l Counter discrepancies is less than 1‰
l Operation stable and lower noise
l Bottle convey smoothly
l Touch screen Control System which is easy to control
l Simple Straight Forward Operator Controls
l Stainless Frame
We adopt electronic scaning counting device on this tablet counting and filling machine which is more pricise than last generation, because this generation could not only count the normal candy but also the transparent candy, that's why we call it candy filling machine. |
MAJOR COMPONENTS:
Specification | Brand |
HMI (7″color touch screen) | Touch screen ( HITACHI) |
Controller of HMI | B-B |
Pix processor | Texas Instruments |
Pix collection unit | TOSHIBA |
ARM processor | SAMSUNG |
Communication chip | Max Integrated |
Relay | OMRON |
Logic inspection system | PHILIP |
Bottle inspection sensor | AUTONICS |
Power switch | MEANWELL |
Transformer | KEWEI |
Motor | MEISTER |
Stainless steel | SS304 |
Steel frame | BAO Steel |
Cylinder | AIRTAC |
dedicated to packaging machinery manufacturing and design for nearly 30 years. During so long time, we have extended our business to become a supplier of complete packaging line including bottle washer, unscrambler, filling and counting machine, inserting machine, labeling machine, capping machine, sealing machine, cartoning machine and so on. We believe that we possess rich experience and ability to meet a variety of requirements of you. Besides, we also provide very good after-sales service and solution of technology problem. We also provide training, on-site installation, documents support. We could make customized products based on different requirements of different customers. |
If this tablet counting and filling machine is the product you are looking for, pls contact us and ask for more detail information about it, you could also put forward some particular requirements about the machine you need exactly because we possess rich experience in customized business. |
1. One year warranty, free charge for spare parts in warranty 2. Engineer available to service overseas 3. Good quality competitive price. ISO9001:2008 and CE certificate 4. You could ask for help about technical problem from our engineer through phone call orinternet any time for free. |
Q1: As an oversea buyer, I am wondering whether you will send your repairman or engineer to our country to help us to solve our problem after one year warranty. A1: Of course, we will always do our best to solve your problem whatever in one year warranty or not, and you need not to pay for unnecessary, we will provide a reasonable repair price to satisfy you.
Q1: Are you a factory or an agent? A1: We are an OEM, we always design and manufacture our products ourselves, so we could provide satisfactory technical and after-sales service. You could pay a visit to our factory any time if you are willing to.
Q3: How does your factory do regarding quality control? A3:Quality is priority! Every worker keeps the QC from the very beginning to the very end, all material we used are meet GB standard, skillful workers care every detail in handing each process, Quality control department specially responsible for quality checking in each process. |
