Help CenterTablet Automatic Counting Machine (CCD-16) (capsule Automatic Counter) Quality Choice
Related Products
-
Economical Automatic Gum Counting MachineUS$ 10,000 - 20,000MOQ: 1 Set -
Economical Automatic Gum Counting and Filling MachineUS$ 10,000 - 20,000MOQ: 1 Set
-
High Speed and Economical Hard Candy Filling MachineUS$ 10,000 - 20,000MOQ: 1 Set
-
High Speed and Economical Hard Candy Counting and Filling MachineUS$ 10,000 - 20,000MOQ: 1 Set
-
New Generation Hot-selling Hard Candy Counting and Bottling MachineUS$ 10,000 - 20,000MOQ: 1 Set
TECHNICAL PARAMETERS:
Counting & Filling Speed |
2000-4000 pieces/minutes based on 20-999 pieces/bottle |
Channel |
12 |
Diameter of bottle |
35-100mm |
Height of bottle |
40-240mm |
Dimensions |
1800mm×1540mm×1600 mm ( L × W × H) |
Weight |
650kg |
Electrical Requirements |
800W, 220v, 50-60HZ(Optional) |
Working direction |
Left → Right (or Right → Left) |
KEY FEATURES:
l CCD technology with high speed digital camera
l Highly anti-dusty design
l Suitable for various capsule with different transparency
l Speeds up to 60 cpm based on 100-count bottles with vibration system
l Counter discrepancies is less than 1‰
l Operation stable and lower noise
l Bottle convey smoothly
l Touch screen Control System which is easy to control
l Simple Straight Forward Operator Controls
l Stainless Frame
CCD-12 tablet counting and bottling machine adopts most advanced image scan
system (CCD technology), the machine consists of 3 grade vibration, 12-channel
feeder, computer control, dynamic camera scan counting system, transfer bottle
automatically. This machine designed with GMP standard. Composed light,
electric into one set, which is suitable for tablet, capsule, gum, clear gel capsule.
It is widely used in pharmaceutical or food industry.
MAJOR COMPONENTS:
Specification |
Brand |
HMI (7″color touch screen) |
Touch screen ( HITACHI) |
Controller of HMI |
B-B |
Pix processor |
Texas Instruments |
Pix collection unit |
TOSHIBA |
ARM processor |
SAMSUNG |
Communication chip |
Max Integrated |
Relay |
OMRON |
Logic inspection system |
PHILIP |
Bottle inspection sensor |
AUTONICS |
| Power switch | MEANWELL |
| Transformer | KEWEI |
Motor |
MEISTER |
Stainless steel |
SS304(PUXIANG) |
Cylinder |
AIRTAC |
If CCD-12 meet your requirements,please contact me for more
details about this counting machine, we could make customized
product based on customers' different demands.
