Help CenterHigh Speed and Economical Candy Counting and Filling Machine
Related Products
-
High Precision Desktop Counting MachineUS$ 5,000 - 10,000MOQ: 1 Set -
Automatic Disc-type Capsule Counting MachineUS$ 5,000 - 15,000MOQ: 1 Set
-
New Generation Hot-selling Candy Bottle Filling Machine Quality ChoiceUS$ 10,000 - 20,000MOQ: 1 Set
-
New Generation Hot-selling Candy Counting MachineUS$ 10,000 - 20,000MOQ: 1 Set
-
New Generation Hot-selling Candy Bottling MachineUS$ 10,000 - 20,000MOQ: 1 Set
Model |
candy counting and filling machine |
Counting & Filling Speed |
3000-6000 pieces/minutes based on 20-999 pieces/bottle |
Channel |
16 |
Diameter of bottle |
35-70mm |
Height of bottle |
40-240mm |
Dimensions |
1800mm×1600mm×1650 mm ( L × W × H ) |
Electrical Requirements |
500W, 220v, 50-60HZ(Optional) |
Weight |
280kg |
Working direction |
Left → Right (or Right → Left) |
l Speeds up to 60 cpm based on 100-count bottles with vibration system
l Counter discrepancies is less than 1‰
l Operation stable and lower noise
l Bottle convey smoothly with dual-track conveyor
l full-set protecting device keep operation steady and reliable
l Touch screen Control System which is easy to control
l Simple Straight Forward Operator Controls
l On-Screen trouble description which is easy to solve
l Stainless Frame
|
This bottled candy filling machine combines 16-channel counting heads over a dual-track conveyor on a single frame to double the throughput without doubling the floor space, achieving speeds up to 60 cpm based on 100-count bottles. The machine handles a wide variety of candies,both hard and soft candies of different shapes, sizes and properties. |
Major components:
Specification |
Brand |
HMI |
SIEMENS |
PLC |
SIEMENS |
PLC extending module |
SIEMENS |
Communication cable |
SIEMENS |
Relay |
OMRON |
Sensor |
NS |
Logic inspection system |
PHILIP |
Bottle detecting sensor |
AUTONICS |
Power switch |
MEANWELL |
Transformer |
GBL |
Motor |
MEISTER |
Stainless steel |
SS304 |
Cylinder |
AIRTAC |
Squarestar Machinery was established in Shanghai, PR China in 1985, since that, we have dedicated to packaging machinery manufacturing and design for nearly 30 years. During so long time, we have extended our business to become a supplier of complete packaging line including bottle washer, unscrambler, filling and counting machine, inserting machine, labeling machine, capping machine, sealing machine, cartoning machine and so on. We believe that we possess rich experience and ability to meet a variety of requirements of you. Besides, we also provide very good after-sales service and solution of technology problem. We also provide training, on-site installation, documents support. We could make customized products based on different requirements of different customers. |
If this candy counting and filling machine is the product you are looking for, pls contact us and ask for more detail information about it, you could also put forward some particular requirements about the machine you need exactly because we possess rich experience in customized business. |
|
1. One year warranty, free charge for spare parts in warranty 2. Engineer available to service overseas 3. Good quality competitive price. ISO9001:2008 and CE certificate 4. You could ask for help about technical problem from our engineer through phone call orinternet any time for free. |
|
Q1: As an oversea buyer, I am wondering whether you will send your repairman or engineer to our country to help us to solve our problem after one year warranty. A1: Of course, we will always do our best to solve your problem whatever in one year warranty or not, and you need not to pay for unnecessary, we will provide a reasonable repair price to satisfy you.
Q1: Are you a factory or an agent? A1: We are an OEM, we always design and manufacture our products ourselves, so we could provide satisfactory technical and after-sales service. You could pay a visit to our factory any time if you are willing to.
Q3: How does your factory do regarding quality control? A3:Quality is priority! Every worker keeps the QC from the very beginning to the very end, all material we used are meet GB standard, skillful workers care every detail in handing each process, Quality control department specially responsible for quality checking in each process. |
