Specifications
1 adsorption style2 wind control device
3 gimble drive , independent gear box
4 pneumatic control
5 high qulity steel
SF280S-360S adsorption single facer machine
Usage;
1 designed speed:120m/min-180m/min
2 diameter of flute roller:280mm-360mm
3 effective width : 1400-2500mm
4 vacuum suction type pulling paper with wind control device
5 the gimble drive with independent gear driven box, transmission more stable , close style gear transmission oilness lubricated, prolong the use life of gear.
6 the gluing roller and fixed roller are designed groups guide way alippage. load-unload is convenient and swift.
7 the upper roller and pressure roller,gluing roller are controlled by pneumatic .
8 manual adjustment or electric adjust gluing quantity.
9 the corrugated roller and pressure roller are made by high temperature resisant lubrication grease.
10 the upper-lower corrugated roller are made by 48CrMo high quality alloy steel, after heat-treament, the rigidity is HRC58-60 degree, the surface are whetted and plating chrome.
11option: electric insulating glue device. gluing part can running separately when machine stop to prevent glue from dry.
12 flute style:A,B,C,E are available or depends on customers.
