Best Price 100kg per Hour Floating Fish Feed Automatic Pellet Making Machine for Sale

Best Price 100kg per Hour Floating Fish Feed Automatic Pellet Making Machine for Sale photo-1
Best Price 100kg per Hour Floating Fish Feed Automatic Pellet Making Machine for Sale photo-2
Best Price 100kg per Hour Floating Fish Feed Automatic Pellet Making Machine for Sale photo-3
Best Price 100kg per Hour Floating Fish Feed Automatic Pellet Making Machine for Sale photo-4
Best Price 100kg per Hour Floating Fish Feed Automatic Pellet Making Machine for Sale photo-5
Best Price 100kg per Hour Floating Fish Feed Automatic Pellet Making Machine for Sale photo-6
US$ 1,500 - 4,039 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
Mingyang
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Henan, China
Brand Name Mingyang
Model Number PH-65
Type Feed Pellet Machine
Voltage 380V
Power(W) 11+0.75kw
Dimension(L*W*H) 1.2*0.7*0.85m
Weight 420 kg
Certification ISO9001
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas
Product Description

The information of automatic pellet making machine

The automatic pellet making machine can make kinds of feed for different fishs, such as food fish, catfish, shrimps, crab, eet, etc. the fish pellet made by the machine can float on water more than 24 hours.

The automatic pellet making machine apply to the pretreatment of the animal fodder so as to reduce loss of nutrition, advance the portein content.

The raw material of corn powder pellet making machine

raw materials need grind into less than 2mm, moisture content : 20-25%
raw materials can be: corn,wheat, rice,corn, broomcorn,maize, beans, soybean, grain, bone powder etc.

The  application of automatic pellet making machine

1.automatic pellet making machine is maily proper for frog, aquatic, ornamental fish, pet feed farmers,
pet feed, fish farmers, Small and Medium feed factory,institutes of scientific research and so on.

2.The raw materials can be wheat, soybean, cake and other leftovers etc.Its main work principle is changing mechanical energy into heat energy to extrude material.

The technical parameter of automatic pellet making machine

we have some type
Type
Screw dia
Power
Capacity
Weight
Machine size(m)
Final size
PH-52
52mm
5.5+0.55kw
50-60kg/h
245kg
1.3*1.0*0.8
1.5-6mm
PH-65
65mm
11+0.75kw
80-120kg/h
420kg
1.2*0.7*0.85
1.5-8mm
PH-75
75mm
15+0.75kw
140-160kg/h
565kg
1.5*1.2*0.9
1.5-8mm
PH-95
95mm
22+0.75kw
250-300kg/h
850kg
1.9*1.25*0.95
1.2-10mm

The working principle of automatic pellet making machine

There is no need to heat outside the machine, through the screw extruding of the raw material, produces heat during the rotary working process, and gathers heat in the airtight environment to reach ripening, during the high temperature ripening process, the starch and fiber of the raw material become swell, on the pressure-tight condition, spray up from the mold outlet through the high pressure produced by the regular rotating of the screw, after cutting by the forepart cutter which rotates regularly and high-speedily, the finished product will be shrunk and become small average ball.

Main Features of automatic pellet making machine

1.According to different requirements, variety shapes of high-grade feed pellets for fish, shrimps .etc

2.The finished pellets can keep floating for 12 hours without pollution to water.

3.The floating time can be controlled by the puffing degree adjustment

4.automatic pellet making machine can make pellet from diameter 1mm-12mm just by changing the mould.

5.Electric heating device is adopted which can improve the feed expansion rate and pellets floating time.

6.High temperature and high pressure cooking process can kill the salmonellosis and bacterial infections and

also makes the pellets easily to digest.

7.The cutting device can be adjusted to make pellets of different length.

The final product of automatic pellet making machine

Production of buoyancy puffed feed particles can maintain at least 12 hours don't bubble floating in the water, fish and livestock to eat easy to digest, artificial can easily observe the frog fish to eat, not cause waste of feed,

Packing & Delivery

The packing and shipping of automatic pellet making machine

automatic pellet making machine  packing in the plywood boxes or wooden cases, then put into the 20 feet or 40 feet container in delivery as follows.
