Box Making Die Cutting Machine

Box Making Die Cutting Machine photo-1
Box Making Die Cutting Machine photo-2
Box Making Die Cutting Machine photo-3
US$ 8,000 - 11,200 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Automatic Grade:
Semi-Automatic
Usage:
Paper Forming Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Automatic Grade Semi-Automatic
Usage Paper Forming Machine
Place of Origin Hebei, China
Brand Name XINGLONG
Model Number MQ1500
Voltage 380v 50Hz
Power(W) 3.0 kw
Dimension(L*W*H) 4*3*1.5 m
Weight about 2000 kg
Certification CE
Warranty One Year
After-sales Service Provided Engineers available to service machinery overseas

     Box making die cutting machine

Use and characteristic:

  1. Use chain straight-through type semi-automatic paper feeding, can make the carton a die-cutting.
  2. Transmission gear adopts the high quality steel precision processing, the spraying circulation to lubricate the system, reduce noise, increase the working life of the gear.
  3. Rubber roller, template roller adopts the high quality steel material, the surface grinding hard chromium plating, after balance correction, increase operation stability.
  4. Template roller and optimal force plastic roller in not die cutting condition through the cylinder and eccentric device automatically take off, can reduce no-load open machine, and provided a optimal power load and glue the life span of the knife mold.
  5. Feeding system with pneumatic automatic lifting devices (send paper roll up first, stop template send paper roll, then template descend, and ensure each cardboard correctly die cutting).
  6. Mechanical transmission optimal force to glue the roll shaft move, and is equipped with 30 mm radial differential device, can make the plastic roller wear average distribution and increase the plastic roller service life.
  7. Adopts the speed difference compensation equipments, need not be automatic adjustment operator intervention rollers speed, to ensure that every batch of carton is in the same size.





MQ1500

Max feeding paper area

1350×1450(mm)

Min feeding paper area

300×500(mm)

Die-cutting accuracy

<±1mm

Cardboard thickness

2—9mm

Working speed

0-60 piece/min

Power (kw)

3.0



 box making die cutting machine

box making die cutting machinebox making die cutting machine

box making die cutting machinebox making die cutting machine

• Our factory is a professional corrugated cardboard carton box making machines manufacturer

  for over 20 years.

• We can provide every customer superior quality products at competitive price.

• If you have any interests about the machine, please feel free to contact me.

• Betty zhang

WhatsApp/Skype:15100856622



• DONGGUANG XINGLONG PACKING MACHINERY CO., LTD.

• ADD: MAHAI INDUSTRIAL AREA SOUTH TO DONGGUANG COUNTY, HEBEI PROVINCE,

  CHINA
