Specifications
Sun feeding full automatic corrugated cardboard rotary die-cutting machine:1 Automatic
2 Lead edge feeding system
Sun feeding full automatic corrugated cardboard rotary die-cutting machine:
Main mechanisms performance:
u Adopts lead edge feeding system. Adjust wind volume according on cardboard bending degree to
ensure feeding paper smoothly.
u The rubber roller with air cylinder device, feeding accurately, stably, not destroy paperboard strength
if the feeding space is very small.
u The left and right side baffles adopt electric adjustment, the front baffle space manual adjustment.
u Equipped with colors touch screen take 360 degree set to die roller, display product speed and set
production quantity.
u The rubber roller adopt mechanical control the position move left and right. The movement distance is 40mm.
u The space of rubber roller with die roller adopt automatic locking device. And with air cylinder can adjust quickly,
reduce rubber wear, prolong use lift.
u With speed compensation device make rubber roller rotate with die roller, make the surface speed of the rubber
cushion is completely controlled by dies. The shape of the carton will able solutely equal to the dies.
u With rubber repair device, the rubber can be used after repairs.
u All of rollers are made of good quality steel Surface be grinded, tempering , hard chromed plate.
u Drive roller used good quality alloy steel, after heat treatment, be grinded. Gear closed cycle spray lubrication,
automatic balance engine oil device, keep every unit oil level is equal.
u Main motor use frequency converter adjustment.
Technical Parameter:
|
Model |
Working efficiency(sheets/min) |
Paper-feeding area(mm) |
Effective die-cutting size(mm) |
SYD4210-1800 |
0-120 |
2000×1270 |
1800×1250 |
SYD4210-2000 |
0-60 |
2200×1270 |
2000×1250 |
SYD4210-2200 |
0-60 |
2400×1270 |
2200×1250 |
SYD4210-2400 |
0-60 |
2600×1270 |
2400×1250 |
The quality first, integrity-based
We are the manufacture which is specialized in producing 3ply, 5ply, 7ply corrugated cardboard production line,
high speed printing machine, ordinary printing machine, single facer, rotary die cutter and other
corrugated cardboard production equipments.
Products are distributed Russia, the Middle East, Africa, Southeast Asia, EU and other countries and throughout
the country. Product quality and enterprise reputation get the high praise at home and abroad.
FAQ
1.Q: Are you a factory or trading company?
A: We are a manufacture which is specialized in the production of various kinds
of carton equipments for over twenty years.
2.Q: Where is your factory located? How can I visit here?
A: Our factory is located in Mahai industrial area south of Dongguang county,
Hebei province, China. It is about 2 hours from Tianjin Train station by car.
We can pick you up if you need, welcome to visit our factory.
3.Q: What are the products of your factory?
A: We are specialized in producing 3ply, 5ply, 7ply corrugated cardboard
production line, high speed printing machine, ordinary printing machine, single facer,
rotary die cutter and other corrugated cardboard production equipments.
4.Q: How is the quality of your product?
A: Over the years our company take “the quality first” “integrity-based” corporate purpose always meet users’ requirements as our sole purpose,
providing the products with excellent quality, professional technology.
5.Q: How is the evaluation of the products?
A: Products are distributed Russia, the Middle East, Africa, Southeast Asia, EU and
other countries and throughout the country. Product quality and enterprise reputation get
the high praise at home and aboard.
6.Q: What is the payment terms?
A: T/T, it is 30% deposit due at placing order and 70% balance due before loading.
