rotary die cutter semi-automatic machinery(MQJ series), carton machinery

Specifications

rotary die-cutting machine:
1 creasing, cut horn, hit especial hole
2 high quality glue sheath
3 Chain feeding

Use and characteristics:





This machine adopt chain provide and double roller cycle roll, take carton piece through many working

procedure of disport, roll line, cut horn, hit especial hole etc. It is ideal equipment of effect all processing

carton piece working procedure one time. This machine has grind cut E style corrugating cardboard, glue

roller line speed auto repair and glue sheath restore function. Grind roller 360° manual adjust. It has grind high nicety and operation convenience and glue sheath using long life and low cost



Type	Max feeding paper area(mm)	Min feeding paper area(mm)	Paperboard thickness(mm)	Total power(kw)
MQJ-1600B	1600×1350	300×500	1-8	4.0
MQJ-1800B	1800×1350	300×600	1-8	5.5
MQJ-2000B	2000×1600	400×600	1-10	7.5
MQJ-2400B	2400×1600	400×700	1-10	7.5
